China Factory Manufacture Jaw Crusher Machine with CE

Shanghai Zenith Mineral Co., Ltd.
  • Type:Jaw Crusher
  • Application:Construction, Mineral Industry, Stone Industry
  • Drive:Hydraulic
  • Crushing Style:Extruding & Milling
  • Compressive Strength (For Crushing):>300MPA
  • Crushing Degree:Coarse Crusher

Base Info

  • Model NO.:PEW series
  • Finished Surface:Hole Process
  • Certification:CE, ISO, GOST
  • Condition:New
  • Color:Iron Grey
  • Spare Parts Supply:for Whole Year
  • Test&Installation:Engineer Assigned
  • After-Sale Service:for Whole Using Life
  • Export Markets:Global
  • Transport Package:Container, Nude Packs, in Bulk
  • Specification:ISO9001: 2000
  • Trademark:Zenith
  • Origin:Shanghai Zenith, China
  • HS Code:8474209000
  • Production Capacity:40-850tph

Description

Basic Info.

Model NO. PEW series Finished Surface Hole Process Certification CE, ISO, GOST Condition New Color Iron Grey Spare Parts Supply for Whole Year Test&Installation Engineer Assigned After-Sale Service for Whole Using Life Export Markets Global Transport Package Container, Nude Packs, in Bulk Specification ISO9001: 2000 Trademark Zenith Origin Shanghai Zenith, China HS Code 8474209000 Production Capacity 40-850tph

Product Description


1. Brief Introduction of Jaw Crusher Machine:

Jaw Crusher Machinery is widely used in the world market nowadays, for primary crushing of hard rocks and block materials. The large and medium-size crushers are the key products of our company and stand in the front of the industry in the aspect of design and production.

2. Usage and Application of Jaw Crusher machine
The high crushing ratio jaw crusher is one of the most popular equipments in mine industry, it is designed for long life service with minimum maintenance for hard, tough, abrasive material and overload high capacity, so is ideally suitable for primary and secondary crushing. Jaw crusher is widely applied in the areas of mining, smelting, building material, road, railway, metallurgical, hydraulic, chemical industry and so on. It is application for various materials with compression resistance less than 320mpa.

3. The structure of Jaw Crusher machine:

The structure of Jaw Crusher includes Main Frame, Main Axle, Roller Bearings, Eccentric Shaft, Jaw Plates, Side Plates, Toggle Mechanism, Fly Wheels and Springs.

China Factory Manufacture Jaw Crusher Machine with CE

4.The Features of Jaw Crusher machine:
Jaw Crusher is of various types;
Jaw Crusher is suitable for crushing maximum, medium and minimum stones;
The operating principle of Jaw Crusher is easy to be operated;
The structure of Jaw Crusher is simple and it is easy to maintain;

5. Parameters of jaw crusher machine

ModelFeed Opening (mm)Max Feeding (mm)Discharge Opening (mm)REV (r/min)Power (kw)Motor ModelMachine Size (mm)
PEW250×1000250×100022020-403306-37Y250M-6/371400×1850×1310
PEW250×1200250×120022020-403306-37Y250M-6/371400×2050×1310
PEW400×600400×60035035-852506-37Y250M-6/371920×1460×1840
PEW760760×110062075-2002706-110Y315L1-6/1102600×2500×2200
PEW860860×1100720100-2252406-132Y315L2-6/1323300×2320×3120
PEW11001100×1200930150-2752108-185Y355L1-8/1854140×2660×3560
