Waste Material Waste Brick, Construction Waste Jaw Crusher for Fuel
ATAIRAC ENGINEERED PRODUCTS INC(CHINA)- Type：Jaw Crusher
- Application：Machinery & Hardware, Chemical, Construction, Mineral Industry, Stone Industry
- Drive：Electric
- Crushing Style：Extruding & Milling
- Compressive Strength (For Crushing)：>300MPA
- Crushing Degree：Intermediate Crusher
Base Info
- Model NO.：JC
- Finished Surface：Outer Surface Process
- Certification：CE, ISO
- Condition：New
- Color：Yellow
- Input Opening (mm)：1220*400
- Max Feed Size(mm)：320
- Capacity(T/H)：18-80
- Power (Kw)：55
- Css (mm)：25-90
- Origin：China
Description
Basic Info.
Model NO. JC Finished Surface Outer Surface Process Certification CE, ISO Condition New Color Yellow Input Opening (mm) 1220*400 Max Feed Size(mm) 320 Capacity(T/H) 18-80 Power (Kw) 55 Css (mm) 25-90 Origin ChinaProduct Description
Product IntroductionAs One of the most popular construction wast-crushing equipment in the world, DHKS series Jaw Crusher is ideally suitable for primary and secondary crushing. This series jaw crusher has features of large crushing ratio, uniform product granularity, simple construction, reliable operation, easy maintenance, low operating cost and low price. C series jaw crusher has been widely used in mining, smelting, building materials, roads, railways, water conservancy, chemical industry and many other fields.
Product Features
- Optimized symmetrical new type "V" crushing chamber, ensure higher crushing efficiency, higher capacity, the throughput capacity is increased by 15%-20% compared with traditional crushing chamber.
- Discharge opening adjusting is controlled by hydraulic wedge block adjusting system,which can saving both labor and time for our customers.
- Large oblique toggle plate design,which makes the lower cavity-type stroke greater and capacity higher.
- Toggle plate and swing jaw plate are equipped with function of lateral deflection prevention.
- Different teeth type of jaw plate is optional for different materials, to improve crushing performance.
| Model | Input Opening (mm) | Max feed size(mm) | Capacity(t/h) | Power (kw) | CSS(mm) |
| DHKS1610 | 400*250 | 210 | 7-23 | 15 | 20-80 |
| DHKS2416 | 600*400 | 340 | 25-64 | 30 | 40-100 |
| DHKS3020 | 750*480 | 400 | 60-120 | 55 | 50-120 |
| DHKS3624 | 920*600 | 510 | 88-170 | 75 | 65-130 |
| DHKS4230 | 1060*750 | 640 | 90-310 | 110 | 65-200 |
| DHKS4816 | 1220*400 | 320 | 18-80 | 55 | 25-90 |
| DHKS5112 | 1300*300 | 240 | 18-110 | 75 | 20-90 |
| DHKS6016 | 1500*400 | 320 | 60-200 | 90 | 25-90 |
