GBMJ-5B Manual Stone Polishing Machine
Xiamen Great Base Imp & Exp Co., Ltd.- Type：Stone Polishing Machine
- Control：Artificial
- Automation：Manual
- Precision：High Precision
- Application：Granite
- Type for Grinding Machine：Disc Grinding Machine
Base Info
- Grinding Machine Type：Abrasive Polishing Machine
- Grinding Method：Wet Grind
- Condition：New
- Polishing Head：1
- Max.Polishing size：3000X650mm
- Polishing arm vertical stroke：0-520mm
- Polishing wheel diameter：8-60mm
- Spindle rotation speed：100,260mm
- Polishing arm lifting/lowering way：Electric
- Polishing head motor power：5.5kw
- Approximate weight：950kg
- Transport Package：Nude Packing
- Specification：3000x750x1600mm
- Trademark：Great Base
- Origin：Xiamen, Fujian, China
- HS Code：84642090
- Production Capacity：100pieces,Year
Description
GBMJ-5B Arm Polishing Machine is made of high grade cast iron. The polishing arms have thick walls to avoid breakage. The machine net weight reaches 950kg.
Quality bearings used in the arm joints and polishing head ensure the arms swing very flexible and long working life.
A spring system is adopted in the polishing head to create polishing pressure. The polishing pressure is adjustable for different slabs and can be fixed in a certain degree.
Polishing arm lifting/lowering movement is motorized.
GBMJ-5B Arm Polishing Machine is suitable for polishing the kind of slab with thickness not varying too much.
