• Model NO.：PF1010
• Finished Surface：Cut Off Tool
• Condition：New
• Color：Customized
• Installation：Under The Guidance of Engineer
• Warrenty：1 Year
• After-Sale Service：Training, Technical Support, etc.
• Usage：Ore, Rock, Stone, etc.
• Delivery：7-15 Working Days
• Price Advantage：Own Factory Can Offer Best Price
• Transport Package：International Packing Standard
• Specification：ISO, CE, SGS
• Trademark：TYM
• Origin：Henan, China
• HS Code：8474201000
• Production Capacity：39 Sets,Month

Basic Info.

Model NO. PF1010 Finished Surface Cut Off Tool Condition New Color Customized Installation Under The Guidance of Engineer Warrenty 1 Year After-Sale Service Training, Technical Support, etc. Usage Ore, Rock, Stone, etc. Delivery 7-15 Working Days Price Advantage Own Factory Can Offer Best Price Transport Package International Packing Standard Specification ISO, CE, SGS Trademark TYM Origin Henan, China HS Code 8474201000 Production Capacity 39 Sets/Month

Product Description

Product introduction





The PF series hard rock counter-attacking crusher absorbs the domestic and foreign advanced technology. The hard rock whose granularity is less than 60-300mm can be processed. The granularity of 80% finished products is less than 30mm. The output of product is shaped as cube. The crusher is the first choice to make aggregates for high level road and hydraulic electricity industry.
Working principle
When the hard rock counter-attacking crusher works, the electric motor drives the rotor where installed hammers to rotate with high speed. When the materials get into the area which the hammers can be effective, under the impact function of the hammers at a high speed, the materials are thrown to the impact device above the rotor continuously. And then the materials are rebounded from the impact liner to the area where the hammers can be effective to be crushed again. The materials' size from big to small all will be crushed in the impact chamber repeatedly. The process won't stop till the material are crushed to the required size and then will be discharged from outlet.


Type	Rotor size (mm x mm)	Feeder Opening(mm)	Feeding Size (mm)	Production Capacity (t/h)	Motor Power (KW)	Weight (t)
PF-1007	Φ1000×700	400×730	300	35-50	37-55	9.45
PF-1010	Φ1000×1050	400×1080	350	50-80	55-75	12
PF-1210	Φ1250×1050	400×1080	350	70-120	110-132	14
PF-1214	Φ1250×1400	400×1430	350	80-160	132-160	18.58
PF-1315	Φ1320×1500	860×1520	500	160-260	180-260	24.2
