• Model NO.：XZQQ625A
• Automation：Automatic
• Cutting Ability：High Speed
• Control：CNC
• Certification：ISO, CE
• Max. Cut Size(L*W)：3200*2000mm
• Max. Cut Thick：170mm
• Blade Size：400-625mm
• Table Tilt：0-85 Degree Easy for Materials Loading
• Table Rotate：0-360 Degree Stop at Any Position
• Blade Tilt：0-45 Degree for Miter Cut
• Repeat Cutting：99 Repeat Cutting by Program
• Spindle Motor：15kw 20HP
• Transport Package：Plastic Water-Proof
• Specification：Weight: 7200kg
• Trademark：AGA
• Origin：Xiamen, China
• HS Code：84649090
• Production Capacity：200sets,Month

Basic Info.

Model NO. XZQQ625A Automation Automatic Cutting Ability High Speed Control CNC Certification ISO, CE Max. Cut Size(L*W) 3200*2000mm Max. Cut Thick 170mm Blade Size 400-625mm Table Tilt 0-85 Degree Easy for Materials Loading Table Rotate 0-360 Degree Stop at Any Position Blade Tilt 0-45 Degree for Miter Cut Repeat Cutting 99 Repeat Cutting by Program Spindle Motor 15kw 20HP Transport Package Plastic Water-Proof Specification Weight: 7200kg Trademark AGA Origin Xiamen, China HS Code 84649090 Production Capacity 200sets/Month

Product Description

Robust Monoblock Granite Bridge Saw Stone Bridge Saw CNC Machine
Product No.XZQQ625A
1) The most reliable and efficient bridge saw to maximize your granite marble production.
The whole bridge saw is featured with high cutting efficiency, high cutting precision, high stability, easy to operate, specially high value granite and big size marble and quartz.
Stone cutting machine XZQQ625A is made with US standard full of options including mono frame, blade tilting, table tilting and rotating, pendant control panel, touch screen, wireless remote, laser guide, hydraulic pump, etc. Hot sales in market.


2) Maximize your granite marble production with monoblock bridge saw 625A:

1) Automatic blade of the granite bridge saw tilting provides 45° for miter cut very excellent performance in cutting and fabricating grantie marble stones.

2) Main structures of the bridge saw are made of very strong cast iron and stainless steel for protection.

3) Powered table of the bridge saw tilts 0-85 degree hydraulic for easy load of material. It rotates 0°-360° stopping automatically at 45°, 90° and any angle for changing cutting position.

4) This granite bridge saw is PLC control, electric system is very simple and easy to operate. All functions are operated on the color touch screen control panel with live data.

5) Wireless remote provides easy control of the saw making its users very friendly.

6) Besides, stone cutting is guided by laser sensor which shows precision cutting position.

7) Togethering with ultra-high precision rotary encoder positioning and infrared device.

8) Wide bridge structure with crossbeam, large size of slab cutting available.

9) Electric components and parts of good interenational name brand adopted, reliability guaranteed.


3) Granite quartz bridge saw specification:

Blade size	400 - 625 mm   16" - 25"
Cut length	3200 mm    126"
Cut width	2000 mm    78.7"
Cut thick	170 mm     6.7"
Blade tilt	0 - 45°
Table rotate	0 - 360° locked any position
Table tilt	0 - 85°
Spindle motor	15 Kw      20 HP
Size (L×W×H)	6×5×3 m    20'×16'×9.9'
Weight	7200 Kg     16,000 Lbs

FAQ:
1) Payment:
T/T in advance, 30% deposit, 70% before shipment.
2) Delivery time:
The bridge saw can be shipped immediately when machine in stock; 4-5 weeks ready for shipment when machine not in stock.
Time for ocean shipping depends on where you are located.
3) Shipment:
For FOB or CIF price, we will arrange shipment for you.
4) Documents after shipment:
After shipment, we will send all original documents to you by DHL or Tele-Release, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.

Key words:
Stone bridge saw, granite bridge saw, marble bridge saw, quartz bridge saw, stone saw, bridge saw, granite sawing machine, granite cutting  machine, stone sawing machine, bridge cutting machine, quartz cutting machine, granite saw, marble saw, cutting machine, slab cutting machine, cnc machine, cnc cutting machine, china cnc machine, slab cut to size machine, etc.


If you have any questions please feel free to inform us, we're more than happy to serve you!
Please contact: Miss Kay
