Stone Machine CNC Processing Center for Countertop with Automatic Tool Change Hualong Machinery Hlcnc-3015
Fujian Province Hualong Machinery Co., Ltd.- Type：CNC Cutting Machine
- Usage：Ceramics, Granite, Marble
Base Info
- Model NO.：HLCNC-3015
- Application：Machinery & Hardware, Art & Craft, Construction, Stone Industry
- Source Voltage：380V
- Automation：Automatic
- Cutting Ability：High Speed
- Control：CNC
- Certification：ISO, CE
- Dimensions of Working Table：3000*14600mm
- Tool Change Positions：20PCS
- Tool Holder Model：40bt
- Stroke (Y-Axis)：1450mm
- Stroke (Z-Axis)：320mm
- Cutting Thickness (Max)：50mm
- Max. Processing Length and Width：3000mm,1460mm
- Guide Rail：Linear Guide
- Gearing：Rack Gear
- Tools Change：Automatically
- Vacuum Cup：Included
- Weight：4000kgs
- Cross Power：7.5kw
- Transport Package：Polypropylene Plastics Packing
- Specification：550X320X230cm
- Trademark：Hualong
- Origin：Putian, Fujian, China
- Production Capacity：50 Sets Per Month
- Package size per unit product：550.00cm * 320.00cm * 230.00cm
- Gross weight per unit product：4000.000kg
Description
Main Features
1) Powered by numerical control planning and interfaced with our CAD / CAM software, their automatic tools allow for calibration,
milling, carving, honing and polishing slabs continuously and automatically in one go.
2) Bilateral tools-store with 20 stations for automatic tool change3 axis Yaskawa servo driver, high speed, high efficiency,fine
cutting without serrated ripple,smooth bottom plane,clear outline..
3) Crossbeam and carling adopt Taiwan's Hiwin linear guide to move, which ensure high precision of cutting and long life.
4) 3 axis Yaskawa servo driver,high speed, high efficiency,fine cutting without serrated ripple,smooth bottom plane,clear outline.
5) With vacuum cups and aluminum alloy lock to double holding the working pieces, avoiding even little displacement
6) Equipped with USB interface for operator to input and output program conveniently.
7) High speed and low noise.
8) High efficiency and low processing cost.
Our Service
·All of our machine will be full-checked and tested by our quality control department before shipment.
·Lifetime technology maintenance in free
·Spare parts supply in free due to our defects within 12 months' warranty time and at cost out of 12 months.
·Free training for installation, operation and maintaince.
·Technical support all working days.
·English version 'instruction books', "Operation Manual" will be offered.
Packaging & Loading
1)All parts wrapped by waterproof PE film and/or air bubbles.
2)Spare and accessary parts of small size packed in plywood cartons.
3)With steel ropes to fix in container, anti-skid suitable for long distance shipment.
FAQ
Q1: Do You Offer Free Samples?
A1: Normally we don't offer free samples. But further solutions will be discussed respectively upon request.
Q2: Can You Supply Us Wearing Parts For The Bridge Cutting Machine?
A2: Sure, it is our duty.
Q3: How About The Delivery Time After Payment For The Order?
A3: Normally 25-45 days. It depends on the ordered models, quantity and our production duty engaged already.
Q4: What Service Can You Provide?
A4: Online technology support, engineers arranged to overseas for guiding machine installation training operation, debugging and maintenance.
