QSM-200 Polishing Machine
Xiamen Great Base Imp & Exp Co., Ltd.- Type：Stone Polishing Machine
- Control：Artificial
- Automation：Automatic
- Precision：High Precision
- Application：Granite
- Type for Grinding Machine：Disc Grinding Machine
Base Info
- Grinding Machine Type：Abrasive Polishing Machine
- Grinding Method：Wet Grind
- Condition：New
- Polishing Head：1
- Max.Polishing size：3200X2000
- Installed total power：12.5kw
- Polishing slab thickness：8-60mm
- Spindle rotation speed：450rpm
- Polishing head transversal moving speed：3780mm,min
- Polishing head longitudinal moving speed：3300mm,min
- Air consumption：0.1 m3,min
- Approximate weight：4200kg
- Transport Package：Nude Packing
- Specification：4500x4340x2420mm
- Trademark：Great Base
- Origin：Xiamen, Fujian, China
- HS Code：84642090
- Production Capacity：100pieces,Month
Description
QSM-200 Bridge Type Single Head Polishing Machine can be used to polish slabs of granite, marble and quartz stone, etc.
Its simple structure design makes it easy for machine installation and maintenance.
The operation is also easy with the integrated control panel, even a worker without any experience can learn to master the machine in short time. Operator just needs to set the polishing head working range in advance on the control panel, the machine will work automatically as per operator's settings.
Polishing head vertical movement and polishing pressure on slab surface is adjustable by pneumatic cylinders.
The polishing head adopts abrasive blocks for polishing and it is fast to change abrasive blocks for different polishing phases.
Slab surface polished by this machine can achieve good flatness and shining gloss.
