• Model NO.：PYB, PYD, PYZ
• Compressive Strength (For Crushing)：250-300MPA
• Crushing Degree：Fine Grinding Machine
• Finished Surface：Gear Process
• Certification：CE, ISO
• Condition：New
• Color：Iron Grey
• Installation：Under The Guidance of Engineer
• Applicaton：Ore
• Delivery：7-15 Working Days
• Warrenty：12 Monthes
• After-Sale Service：Training, Technical Support
• Price：Negotiation
• Transport Package：International Stndard Packing
• Specification：CE, ISO, SGS
• Trademark：TYM
• Origin：Henan, China
• HS Code：8474209000
• Production Capacity：40sets,Month

Basic Info.

Model NO. PYB, PYD, PYZ Compressive Strength (For Crushing) 250-300MPA Crushing Degree Fine Grinding Machine Finished Surface Gear Process Certification CE, ISO Condition New Color Iron Grey Installation Under The Guidance of Engineer Applicaton Ore Delivery 7-15 Working Days Warrenty 12 Monthes After-Sale Service Training, Technical Support Price Negotiation Transport Package International Stndard Packing Specification CE, ISO, SGS Trademark TYM Origin Henan, China HS Code 8474209000 Production Capacity 40sets/Month

Product Description

Usage
The spring cone crusher is applicable for crushing various rocks and ores with medium hardness. The spring cone crusher is widely used in metallurgical, construction, utilities, transport, chemicals, building materials industry, for breaking hard, medium hardness of the above various ores and rock.
Showier spring cone crusher has three types: PYD for tertiary crushing, PYB for primary or secondary crushing, PYZ is used as secondary crushing facility. Every type meets different requirement. Each type of machine has an excellent performance
Features and advantages:
1. Rational structure, advanced crushing principle and technical data, reliable operation and low operation cost.
2. High crushing ratio, high efficiency and high productivity.
3. Reliable spring security system, which can provid effective overload protection.
4. Double-crushing cavity, which meets large range of size requirements.
5. Manual -operating hydraulic discharge opening makes your work easy and economic.




Working principle of cone crushing
Cone crusher crushes materials by the working surface between the movable cone and fixed cone. The movable cone of the cone crusher is supported by spherical bearing and fixed on an hanging erect shaft which is set in the eccentric sleeve, and the sleeve is set on the stopping and pushing. The movable cone and erect shaft are drived by the eccentric shaft sleeve together. The eccentric shaft sleeve is driven by horizontal shaft and fimbriated gear, and the wheel of the conveyor belt is drived by motor through v-belts. The lower part of vertical shaft is installed in the eccentric sleeve. When the eccentric sleeve of cone crusher rotates, there is a conical surface lined out by the shaft. When the movable cone comes near the fixed cone, rocks are grinded into pieces, when the cone leaves, grinded materials is discharged from the discharge hole. The fixed cone can be ascended or descended by adjusting setting to adjust the width of discharge hole, consequantly the output size is determined.



Type	Diameter	Size of Feeder Size	Adjusting range of output (mm)	Capacity (t/h)	Motor Power (kw)	Weight (T)	Overall dimensions (LWH)(mm)
PYB600	Φ600	12-25	65	40	30	5	2800×1300×1700
PYD600	Φ600	3-15	35	12-23	30	5.5	2800×1300×1700
PYB900	Φ900	15-50	115	50-90	55	11.2	3050×1640×2350
PYZ900	Φ900	5-20	60	20-65	55	11.2	3050×1640×2350
PYD900	Φ900	3-13	40	15-50	55	11.3	3050×1640×2350
PYB1200	Φ1200	20-50	145	110-168	110	24.7	4000×1900×2980
PYZ1200	Φ1200	8-26	100	42-135	110	25	4000×1900×2980
PYD1200	Φ1200	3-15	50	18-105	110	25.3	4000×1900×2980
PYB1750	Φ1700	25-50	250	280-480	160	50.3	4870×3800×4192
PYZ1750	Φ1700	10-30	215	115-320	160	50.3	4870×3800×4192
PYD1750	Φ1700	5-13	100	75-230	160	50.2	4870×3800×4192
PYB2200	Φ2200	30-60	300	59-1000	280/260	80	5420×4300×4870
PYZ2200	Φ2200	10-30	230	200-580	280/260	80	5420×4300×4870
PYD2200	Φ2200	5-15	100	120-340	280/260	81.4	5420×4300×4870

6.contact us
 If you are interested in our products,please feel free to contact with me:
Zhengzhou General Mining Machinery Co.,Ltd.
Contact with Miss. Lily Jin



Office Add: Zhangzhai Industry Zone,

Zhongyuan Western Road, Zhengzhou, China.

We hope our perfect products and service can satisfy you,and welcome to our factory to visit . Looking forward to building long-term relationship with you !
