Hualong Stone Saw Machinery Automatic Electric Laser Stone Cutter Marble Granite Stone Cutting Machine with 45 Degree Tilt 360 Degree Table Rotation

Fujian Province Hualong Machinery Co., Ltd.
  • Warranty：1 Year
  • Type：Laser Cutting Machine

Base Info

  • Model NO.：HLSQ-700
  • Usage：Ceramics, Granite, Marble
  • Application：Machinery & Hardware, Art & Craft, Stone Industry
  • Source Voltage：380V
  • Automation：Automatic
  • Cutting Ability：High Speed
  • Control：PLC
  • Certification：ISO, CE
  • Head Tilting Position：45 Degree
  • Table Rotate：90-360 Degree
  • Table Tilt：0-85 Degree
  • Guide Rail：Linear Guide
  • Gearing：Rack Gear
  • Diamensions of Working Platform：3300*2000mm
  • Blade Diameter：φ400-φ700
  • Max. Processing Dimensions：3200X3200X220mm
  • Transport Package：Plastic Packing
  • Specification：6000x5000x2800mm
  • Trademark：Hualong
  • Origin：Putian, Fujian, China
  • HS Code：84641010
  • Production Capacity：50PCS,Month

Description

 MeasurementGross weightkg6100Dimension (L x W x H)cm600 x 500 x 280

Advantages

1) Durability: Good quality steel is used as the mechanical parts and reliable electric parts are used to guarantee high reliability & durability. 2) Precision:
  a, Crossbeam movement (Y-axis) along V-guide way with high precision.  b, Magnetic ruler is adopted for slicing measure.
  c, Laser device for accurate alignment.
  d, V-guide rail system applies not only in left and right movement of the girder but also in lifting up and down section, thus reduces the error and improves cutting accuracy.3) Use-friendly:
  a, Touch screen control panel and all movement is controlled by PLC to realize operation available.  b, Work table can be tiltable and removable.Hualong Stone Saw Machinery Automatic Electric Laser Stone Cutter Marble Granite Stone Cutting Machine with 45 Degree Tilt 360 Degree Table Rotation
