• Model NO.：K series
• Application：Construction, Mineral Industry, Stone Industry
• Drive：Hydraulic
• Crushing Style：Grinding & Impact
• Compressive Strength (For Crushing)：>300MPA
• Crushing Degree：Intermediate Crusher
• Finished Surface：Hole Process
• Certification：CE, ISO, GOST
• Condition：New
• Color：Iron Grey
• Spare Parts Supply：for Whole Year
• Test&Installation：Engineer Assigned
• After-Sale Service：for Whole Using Life
• Export Markets：Global
• Transport Package：Container, Nude Packs, in Bulk
• Specification：ISO9001: 2000
• Trademark：Zenith
• Origin：China
• HS Code：8474209000
• Production Capacity：80sets,Month
• Package size per unit product：700.00cm * 300.00cm * 400.00cm
• Gross weight per unit product：10000.000kg

Basic Info.

Model NO. K series Application Construction, Mineral Industry, Stone Industry Drive Hydraulic Crushing Style Grinding & Impact Compressive Strength (For Crushing) >300MPA Crushing Degree Intermediate Crusher Finished Surface Hole Process Certification CE, ISO, GOST Condition New Color Iron Grey Spare Parts Supply for Whole Year Test&Installation Engineer Assigned After-Sale Service for Whole Using Life Export Markets Global Transport Package Container, Nude Packs, in Bulk Specification ISO9001: 2000 Trademark Zenith Origin China HS Code 8474209000 Production Capacity 80sets/Month

Packaging & Delivery

Package size per unit product 700.00cm * 300.00cm * 400.00cm Gross weight per unit product 10000.000kg

Product Description

KE1100-1 Wholesale stone crushing machine Competitive Price




stone crushing machine introduction:

stone crushing machine has the advantages of easy transportation, low transportation cost, flexible configuration, convenient maintenance etc. It can be operated as independent units, or as two-stage crushing plant with primary and secondary crushing, or as three stage crushing plant with primary, secondary, and tertiary crushing according to different clients' requirements. Likewise, it can be easily adjusted to suit the crushing application by choosing feeding to crusher or feeding to screen options.

stone crushing machine is developed according to novel series stone crushing equipment's design idea, which expands the concept field of coarse crushing and fine crushing. Its design idea is based on the client's requirements, which clears faults of the crushing place, surroundings and the complex basic configurations. This series mobile coal crusher really supply simpler, higher efficient and lower cost machine for clients.
large rock crusher machine price breaks through the constraint of traditional fixed crushing plants and its high transportation cost. It can deal with materials in nearby site which is widely applied in mining, metallurgy, building material, transportation, water conservancy and other industries. Mobile crusher concept is fully adaptable to all mobile crushing demands; It sets up a new range of business opportunities for contractors, quarry operators, recycling and mining applications. Vipeak mobile coal crusher can eliminate the area of the crushing site, and offer high efficient & low cost project plants for the client. The incorporated setting is easy to maintain and install which makes the mobile crusher plant have long endurance and higher efficiency. There are two types of mobile crusher: Wheeled type mobile crusher and crawler type mobile crusher. Wheeled type mobile crusher is also called tire type mobile crusher, tyre type mobile crusher, rubber-tyre type mobile crusher; Crawler type mobile crusher is also called tracked type mobile crusher, track-mounted type mobile crusher. The mobile crusher manufacturers is usually called mobile crushing plant, mobile crusher station or portable crusher.


stone crushing machine manufacturers

Feeder, belt conveyor and vibrating screen are all in one vehicle.
Turn axle of traction is convenient for road transit and expanding the working place.
Vehicle installation supporting is easier for equipment to station in the working place.
Vehicle electric generating set, motors and control box are all included.

Characteristics of stone crushing machine

1.Flexibility;
2.Lower freight cost;
3.Direct and efficient operation;
4.Easy to adapt and flexible to collocate;
5.Reliable performance and convenient maintenance.

stone crushing machine parameters:

Coarse crushing equipment

Model	Specs. of screening equipment	Specs. of crushing equipment	Specs. of main belt conveyor	Hopper volume(m3)	Max.feeding size (mm)	Transportation dimension(mm)
KE600-1	TSW0936	PE600×900	B800×8.3m	5.3	500	12150×2600×3950
KE750-1	TSW1139	PE750×1060	B1000×8.5m	7	630	13000×2850×4400
KE760-1	TSW1139	PEW760	B1000×8.5m	7	640	13000×2800×4200
KE860-1	TSW1345	PEW860	B1200×9.5m	8	720	14600×3000×4500
KE1100-1	TSW1548	PEW1100	B1400×9.5m	11	930	14050×2900×4000
KJ98-1	TSW1139	HJ98	B800×8.3m	5.9	560	12150×2600×3950
KJ110-1	TSW1345	HJ110	B1000×8.5m	8.5	660	13200×3000×4400
KJ125-1	TSW1345	HJ125	B1400×9.5m	8	800	14600×3000×4500
KF1214-1	TSW0936	PFW1214	B800×8.3m	5.3	500	12150×2600×3980
KF1315-1	TSW1345	PFW1315	B1200×9.5m	8	600	14600×3100×4500
KF1415-1	TSW1548	PFW1415	B1200×9.5m	11	700	14050×3000×4000

Medium and fine crushing and screening portable plant

Model	Specs. of screening equipment	Specs. of crushing equipment	Specs. of main belt conveyor	Max.feeding size (mm)	Transportation dimension(mm)
KC75-2	3Y1848	CS75B	B800×7.5m	150	12600×3000×4500
KC160-2	3Y1860	CS160B	B800×8.5m	205	13800×3000×4500
KT100-2	3Y1848	HST100H1	B800×7.5m	185	12600×3000×4500
KT160-2	3Y1860	HST160H1	B800×8.5m	185	13800×3000×4500
KT250-2	3Y1860	HST250H1	B800×8.5m	215	13800×3000×4500
KH300-2	3Y1860	HPT300C2	B800×8.5m	210	13800×3000×4500
KF1214-2	3Y1860	PFW1214	B800×8.5m	250	13800×3000×4500
KF1315-2	3Y2160	PFW1315	B1000×8.5m	300	13800×3150×4500
KF1318-2	3Y2160	PFW1318	B1000×8.5m	300	13800×3150×4500
KS1848-1	3Y1848	--	B800×7.5m	--	12590×3000×4500
KS1860-1	3Y1860	--	B800×8.5m	--	13800×3000×4500
KS2160-1	3Y2160	--	B1000×8.5m	--	13800×3000×4200

Complete portable plant

Model	Specs. of screening equipment	Specs. of crushing equipmentt	Specs. of main belt conveyor	Hopper volume(m3)	Max.feeding size (mm)	Transportation dimension(mm)
KC75-2D	3Y1848	CS75B	B800×7.5m	7.2	150	16850×3000×4500
KC160-2D	3Y1860	CS160B	B800×8.5m	7.2	205	16850×3000×4500
KT100-2D	3Y1848	HST100H1	B800×7.5m	7.2	185	16850×3000×4500
KT160-2D	3Y1860	HST160H1	B800×8.5m	7.2	185	16850×3000×4500
KT250-2D	3Y1860	HST250H1	B800×8.5m	8	215	16850×3000×4500
KH300-2D	3Y1860	HPT300C2	B800×8.5m	8	210	16850×3000×4500
KF1214-2D	3Y1860	PFW1214	B800×8.5m	7.2	250	16120×3000×4500
KF1315-2D	3Y2160	PFW1315	B1000×8.5m	8	300	16120×3150×4500
KF1318-2D	3Y2160	PFW1318	B1000×8.5m	8	300	16120×3150×4500
KS1848-1D	3Y1848	--	B800×7.5m	7.2	--	16910×3000×4500
KS1860-1D	3Y1860	--	B800×8.5m	7.2	--	16910×3000×4500
KS2160-1D	3Y2160	--	B1000×8.5m	8	--	16910×3000×4500

Sand-making and shaping portable plant

Model	Specs. of screening equipment	Specs. of crushing equipment	Specs. of main belt conveyor	Max.feeding size (mm)	Transportation dimension(mm)
KV8518-2	3Y1848	VSI8518	B800×7.5m	40	14200×3000×4500
KV8522-2	3Y1860	VSI5X8522	B800×8.5m	40	14200×3000×4500
KV9526-2	3Y1860	VSI9526	B800×8.5m	45	14200×3000×4500
KV9532-2	3Y1860	VSI5X9532	B800×8.5m	45	14200×3000×4500

Fine crushing and sand washing portable plant

Model	Specs. of screening equipment	Medium and fine crushing and screening portable plant	Specs. of crushing equipment	Max.feeding size (mm)	Transportation dimension(mm)
KV8518-2X	3Y1848	XL-915	VSI8518	40	13700×3000×4500
KV8522-2X	3Y1860	2XL-915	VSI5X8522	40	13700×3000×4500
KV9526-2X	3Y1860	2XL-915	VSI9526	45	13700×3000×4500
KV9532-2X	3Y1860	2XL-915	VSI5X9532	45	13700×3000×4500
KC75-2X	3Y1848	XL-915	CS75B	150	13700×3000×4500
KC160-2X	3Y1860	XL-915	CS160B	205	13700×3000×4500
KH300-2X	3Y1860	2XL-915	HPT300C2	210	13700×3000×4500
KT250-2X	3Y1860	2XL-915	HST250H1	215	13700×3000×4500

Three-in-one portable plant

Model	Specs. of screening equipment	Model	Specs. of crushing equipment	Hopper volume(m3)	Max.feeding size (mm)	Transportation dimension(mm)
KF1214-3	3Y1848	TSW0936	PF1214	5.5	300	16400×2810×4500
KF1214-3	3Y1848	TSW0936	PFW1214	5.5	500	16400×2810×4500
KE500-3	3Y1548	TSW0936	PE500×750	5.5	425	16400×2760×4500
KE600-3	3Y1848	TSW0936	PE600×900	5.5	500	16400×2760×4500

Four-in-one portable plant

Model	Specs. of screening equipment	Model	Complete portable plant	Sand-making and shaping portable plant	Max.feeding size (mm)	Transportation dimension(mm)
KE400C55-4	3Y1237	GZD960×3500	PE400×600	PYB900	350	15150×2800×4500
KE400C75-4	3Y1237	GZD960×3500	PE400×600	CS75B	350	15150×2800×4500
KE500C55-4	3Y1237	GZD960×3500	PE500×750	PYB900	425	15150×2800×4500
KE500C75-4	3Y1237	GZD960×3500	PE500×750	CS75B	425	15150×2800×4500
KE400F110-4	3Y1237	GZD960×3500	PE400×600	PF1010	350	15150×2800×4500
KE500F110-4	3Y1237	GZD960×3500	PE500×750	PF1010	425	15150×2800×4500
