• Model NO.：BD3020-H
• Certification：CE, ISO
• Current：AC
• Application：Advertising, Stone Industry
• Customized：Customized
• Configuration：2.2kw Water Cooling Spindle
• Drive Motor：Stepper Motor
• Control System：Nc Studio Nk260
• Working Voltage：AC380V 3pH 50Hz
• Guide Rail：Taiwan Imported Linear Guide Rail
• Transport Package：Plywood Case Package
• Specification：3000KG
• Trademark：Mars
• Origin：China
• HS Code：8458110090
• Production Capacity：300,Month

Basic Info.

Model NO. BD3020-H Certification CE, ISO Current AC Application Advertising, Stone Industry Customized Customized Configuration 2.2kw Water Cooling Spindle Drive Motor Stepper Motor Control System Nc Studio Nk260 Working Voltage AC380V 3pH 50Hz Guide Rail Taiwan Imported Linear Guide Rail Transport Package Plywood Case Package Specification 3000KG Trademark Mars Origin China HS Code 8458110090 Production Capacity 300/Month

Product Description

Superior quality ZS1825-1H-2S Wood CNC Router Engraving Machine
Keywords:15 years experience of production
                   ISO9001:2008, CE, SGS, AAA Level Enterprise which Honors Contract
                   Three Brand: Mars, Boiro, Golden Eagle
                   Technicist who go abroad to offer after-sale service




 Products Parameter

Basic	X/Y/Z Axis Working Area	3000*2000*330mm
	Machine Size	5240*2770*2800mm
	Working Table	Aluminum T-slot table protected with PVC
	Machine Structure	Thick steel welded, with aging treatment
Main	Control System	NC Studio NK260
	Drive Motor	Leadshine (Optional with Stepper)
	Spindle Motor Power	1*5.5KW water cooled; Adjustable Rotational Speed with 0-24000 rpm/min
	Inverter	Zoncn (Optional with Fuling)
Others	Drive System	X/Y axis helical rack & pinion, Z axis Taiwan ball screw
	Guide Rail	Taiwan imported linear guide rail
	Cooling System	Water Circlation Cystem
	Resolution	0.01 mm
	Max. Traveling Speed	25 m/min
	Max.Working Speed	15 m/min
	Water Sink/Tank	Powder-painting (Stainless steel is optional)
	Dictate Format	G-Code / HPGL
	Working Voltage	AC380V 3PH 50HZ
	Remark	Hydraulic flip material

Main Useage


Application Scop:

Widely used in stone processing industry,tombstone processing industry,mold processing industry,all kind of art relief, decoration industry,ceramic processing,advertising industry;be applied for the 3D relief of marble,jade,granite,tombstones,milestones,ceramic tiles,glass,bluestone,etc., or 2D sculpture,cutting,chamfering,drilling,ect..
