• Model NO.：M7130C
• Grinding Machine Type：Vibration Polishing Machine
• Grinding Method：Semi-Dry Grind
• Condition：New
• Table Size(Wxl)：300X1000 mm
• Max. Machining Dimension(Wxl)：300X1000 mm
• Max. Distance Between Spindle：1375mm
• Longitudinal Moving Speed of Worktable：5-25m,Min
• T-Slot Number X W：3X18(mm)
• Transport Package：Plywood
• Specification：CE
• Trademark：customer brandv
• Origin：China China
• HS Code：8466200
• Production Capacity：50sets, Per Month

M71 wheel head moving surface grinder  Item/ModelUnitM7130Ctable size(WxL)mm300x1000max. machining dimension(WxL)mm300x1000max. distance between spindle center line and worktable surfacemm1375longitudinal moving speed of worktablem/min5-25T-slot number x Wmm3x18wheel head cross movingcontinuous feed speedm/min0.5-4.5intermittent feed speedmm/t3-30hand wheel feedmm/gra wheel head vertical movingrapid speedmm/min400feed of handwheelmm/gra0.005wheel head motorpowerkw5.5rotation speedrpm1440total powerkw9max. loading capacity of worktable with chuckkg470chuck size (W x L)mm300x680x1wheel size (ODxWxID)mm350x40x127machine dimension(LxWxH)cm286x154x293package dimensions(LxWxH)cm284x171x303machine weightt4
