Multi Blades Marble Mosaic Cutting Machine Mosaic Tile Making Machine

Xiamen Great Base Imp & Exp Co., Ltd.

function：mosaic machine
main motor：22kw
Key word：marble mosaic cutting machine
Transport Package：Wooden Box Package
Specification：2500*1000*1700mm
Trademark：Great Base

Base Info

Model NO.：GBPGP-300
Origin：China
HS Code：84641090
Production Capacity：300sets,Year

Description

GBPGP-300No. of spindle head 1pcBelt width 320mmBlade diameter¢300-¢400 mmMain motor22kwMotor of belt1.5KW Up/down motor 0.55KWMax. cutting width300mm Max. cutting thickness 150MM Total power24.05kw Belt speed1-3m/minuteDimension 2500*1000*1700mmTotal weight 1400kg

Multi Blades Marble Mosaic Cutting Machine Mosaic Tile Making Machine

Category

Artificial Stone Machinery

Other Stone Processing Machinery

Stone Carving Machine

Stone Crusher

Stone Cutting Machine

Stone Drilling Machine

Stone Polishing & Grinding Machine

Recommended

Mosaic Stone Calibration Machine Mosaic Making Machine
NameUnitGBPG-400DGBPG-600DGBPG-800DGBPG-1000DSpindle headpcs2222Belt widthmm4506508501050Calibration pad diametermm¢450¢650¢850¢1050Max. processing widthmm4006008001000Max. processing thicknessmm60606060Main motor powerkw1518.518.518.5Belt motor powerkw1.51.51.51.5Total powerkw32
Hydraulic Multi Discs Stone Cutting Machine Granite Cutting Machine
NameUnitGBQQJ-2000GBQQJ-2500CBlade diameter mmTotal 6pcs, Max.Ф2000Total 9pcs, Max.ф2500Max. cutting sizemm3500*2300*8003200*2300*1050Main motor power kw4555Girder length mm75007500Water consumption m3/h1212Weightkg900010000
Stone Dust Cleaning Machine for sale
NameUnitGBSQ-30GBSQ-40GBSQ-50Fan motorkw1.11.11.1Fan model/SFG-6-4SFG-6-4SFG-6-4Fan numberpcs345Air pressurekpa0.60.60.6Total air volumem³/h37500-4000050000-6000062500-75000Clean effect/Above 90%Above 90%Above 90%Suction of equipmentm/s1.8-2.21.8-2.21.8-2.2Noise valuedb80-8580-8580-85Dimension(
Pulsed Stone Dust Dry Cleaning Machine for sale
NameUnitGBML-S-30GBML-S-40GBML-S-50Fan motorkw2.22.22.2Fan model/GFK4.SDFK4.SDFK4.SFan numberpcs234Air pressurekpa0.60.60.6Total air volumem³/h16000-2400024000-3600032000-48000Clean effect/Above 99.7%Above 99.7%Above 99.7%Pulse control device/Sxc-8A1-4Sxc-8A1-4Sxc-8A1-4Suction of equipmentm/s2.
GBPGP-300 Automatic Continuous Cutting Machine
GBPGP-300No. of spindle head 1pcBelt width 320mm Blade diameter ¢300-¢400 mmMain motor 22kw Motor of belt 1.5KW Up/down motor 0.55KW Max. cutting width 300mm Max. cutting thickness 150MM Total power 24.05kw Belt speed 1-3m/minute Dimension 2500*1000*1700mmTotal weight 1400kg Main Features1
GBPGL-300 Mosaic Shaping Machine/Granite/Marble Machine
NameGBPGL-300No. of blade1pcMax. cutting width200mmMax. cutting length600mmMain motor11kwProcessing speed1-6m/minuteUp/down motor0.55kwDimension1550*1250*1700mmTotal power11.92kwTotal weight1100kgMain Features1) Machine with competitive price and high quality ,easy in installation and maintenance.2)
GBPGM-200 Mosaic Rounding Machine/Granite/Marble Machine
GBPGM-200 Belt motor 3kwTotal power3.37kwTotal weight300kgMax. molding size 200mmMax. cutting length200mmDimension1250*750*1350mmUp/down motor 0.37kwMain Features1) Machine with competitive price and high quality ,easy in installation and maintenance.2) Adopting advanced world famous brand component
GBPGL-300 Mosaic Machine/Granite Machine/Marble Machine
NameGBPGL-300No. of blade1pcMax. cutting width200mmMax. cutting length600mmMain motor11kwProcessing speed1-6m/minuteUp/down motor0.55kwDimension1550*1250*1700mmTotal power11.92kwTotal weight1100kgMain Features1) Machine with competitive price and high quality ,easy in installation and maintenance.2)
