• Model NO.：ZP SERIES
• Control：Electricity
• Motor Power：High Power
• Engraving Head Speed Adjustability：No
• Certification：CE, ISO
• Current：AC
• Application：Glass
• Customized：Customized
• Zp：35
• Transport Package：Fumigated Wooden Case
• Specification：CE, ISO
• Trademark：Sun world
• Origin：China
• HS Code：84388000
• Production Capacity：20,Month
• Package size per unit product：100.00cm * 120.00cm * 165.00cm
• Gross weight per unit product：1400.000kg

Basic Info.

Model NO. ZP SERIES Control Electricity Motor Power High Power Engraving Head Speed Adjustability No Certification CE, ISO Current AC Application Glass Customized Customized Zp 35 Transport Package Fumigated Wooden Case Specification CE, ISO Trademark Sun world Origin China HS Code 84388000 Production Capacity 20/Month

Packaging & Delivery

Package size per unit product 100.00cm * 120.00cm * 165.00cm Gross weight per unit product 1400.000kg

Product Description

It is a special machine for using glass powder to form various shaped and sized mosaic. Size ranges from 12× 12mm, 15× 15mm, 20× 20mm, 23× 23mm, 25× 5mm etc. For different size mosaic making, just change the forming mould. This machine equipped with our automatic block bedding machine to make a complete mosaic automatic production line.

Normal production flow: Glass powder---mosaic pressing machine---auto block bedding machine---kiln firming-- -finished product.
Feature:
1. Speed controlled by inverter. Adjustable.
2. Trial and commissioning can be done without stopping the machine.
3. All controllers and components are reasonable arranged and convenient for operation.
4. Suitable for large and irregular piece.

Die numbers  (set)	33	25	15
Max. pressure( KN)	40	60	120
Max. diameter (mm)	16.5*16.5	20	40
Max. filling depth (mm)	15	20	30
Max. mosaic thickness (mm)	6	9	15
Rotate speed (rpm)	11-28	6-15	10-25
Capacity  (pc/h)	17000-43000	18000-30000	9000-22500
Power   (Kw)	3	3	7.5
Dimension (mm)	950×960×1600	1100×1100×700mm	900×800×1640
Weight (Kg)	850	1800	1500
