• Model NO.：PE
• Finished Surface：Gear Process
• Condition：New
• Color：Red
• Model：Pex-250*1200
• Max. Feed Size：210mm
• Size of Ourput：25-60
• Capacity：20-60t,H
• Motor Power：37-45kw
• Overall Dimension：2192*1900*1950mm
• Weight：8.5t
• Delivery：7-15 Working Days
• After-Sale Service：Training, Technical Support
• Transport Package：Standard Packing or as Your Request
• Specification：CE, ISO, SGS
• Trademark：TYM
• Origin：Henan, China
• HS Code：8474209000
• Production Capacity：50sets,Month

Basic Info.

Model NO. PE Finished Surface Gear Process Condition New Color Red Model Pex-250*1200 Max. Feed Size 210mm Size of Ourput 25-60 Capacity 20-60t/H Motor Power 37-45kw Overall Dimension 2192*1900*1950mm Weight 8.5t Delivery 7-15 Working Days After-Sale Service Training, Technical Support Transport Package Standard Packing or as Your Request Specification CE, ISO, SGS Trademark TYM Origin Henan, China HS Code 8474209000 Production Capacity 50sets/Month

Product Description

PE series Jaw crusher, jaw crusher machine with CE and ISO Approval

1.Energy-Saving about 20%~35%.
2.Most professional jaw crusher.
3.Stable performance
4.Most Competitive Price


High quality PE series Jaw crusher with CE and ISO Approval

Jaw crusher is easy to install, operate and maintain. As per feedback, our experts will make continuous improvements on our products to meet customers' changing needs. Every feature of TYM jaw crusher has been carefully designed to provide superior quality and performance. It is widely used in fields of mining, metallurgy, construction, smelting, hydropower and chemical industries etc. TYM jaw crusher has competive jaw crusher price for you.

Jaw crusher working principle

The working principle of jaw crusher is very simple. The whole crushing process rely on the relative motion of the two jaw plates. One of the jaw plates stay still while the other move against it. And with the movement, the materials between the two plates would be crushed into small elements. While the plates move against each other, the materials would be crushed and while plates move away from each other, the broken materials which are smaller enough would drop through the discharging opening. And due to the simple structure, jaw crusher is easy to maintain and repair. These features promote its popularity to a great extant.

Jaw crusher main Features and Advantages:

1. High efficiency and low operation cost
2. Flexible capacity
3. Simple structure and easy to operate
4. Over loading protection
5. Easy replacement of wearing parts
6. Long service life
7. High reliability
8. Wide ranges of choices
9. Alternative ordinary and hydraulic types

Model	Size of Feeder Opening(mm)	Max. Feeding Size (mm)	Capacity (t/h)	Motor Power (kW)	Overall Dimensions (mm)	Weight (t)
PE150×250	150×250	125	1-3	5.5	896×745×935	0.8
PE200×350	200×350	180	1-6	11	996×800×760	1.2
PE250×400	250×400	200	5-20	15	1430×1310×1340	3
PE400×600	400×600	350	15-60	30--37	1700×1732×1653	7
PE500×750	500×750	425	50-100	45--55	2035×1921×2000	12
PE600×900	600×900	480	60-130	55--75	2290×2206×2370	17
PE750×1060	750×1060	630	80-180	90--110	2655×2302×3110	29
PE900×1200	900×1200	750	140-260	110-132	3789×2826×3025	58
PEX250×750	250×750	210	10-40	22--30	1667×1545×1020	5
PEX250×1000	250×1000	210	15-50	30--37	1550×1964×1380	7
PEX250×1200	250×1200	210	20-60	37--45	2192×1900×1950	8.5
