Laser Granite Edge Cutting and Polishing Machine Stone Tile Cutter Affordable Price (HQ400)
Xiamen Aga Import and Export Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Laser Cutting Machine
- Usage：Granite, Marble
- Application：Stone Industry
- Source Voltage：220V
Base Info
- Model NO.：HQ400
- Automation：Automatic
- Cutting Ability：High Speed
- Control：CNC
- Certification：ISO
- Model No：Hq 400
- Dimention：6*2.5*2.8m
- Table Rotation：0-90degree
- Spindle Motor：15kw
- Table Tilting：0-85degree
- Max Cut Thick：80mm
- Max Cut Size(L*W)：3200*2000
- Table Size(L*W)：3200*2000
- Max Blade Size：400mm
- Transport Package：20gp
- Specification：6m*2.5m*. 8m
- Trademark：AGA
- Origin：China
- HS Code：84141080
- Production Capacity：50sets,Month
Description
Feartures and Benifits
1.Mono-block structure, side beams are fixed on the steel, solid and stable.
2.Equipped with infrared device for precise cutting location
3.Wide crossbeam of bridge structure for large size of slab cutting and it is made of strong cast iron to avoid distortion after long-term use.
4.Guide rail on the crossbeam is in oil bath and it is protected from water and dust
5.Dustproof design of the slide track ensures the precise guide movement & long lifespan
6.Vertical movement of machine head is driven by accurate hydraulic system, and the stroke is adjustable
7.Cross movement of the machine head on the crossbeam is driven by motor equipped with OMRON rotary encoder by which the precision is guaranteed
8.The crossbeam is installed on the side beams by lineal guide track that results in less friction force and provides better flexibility and reliability
9.Worktable can tilt 0-85°
10.Equipped with PANASONIC frequency transducer and PLC, programmable and fully automatic
11.Touch-sensitive operating system, friendly human-machine interface design
