Full Automatic Infrared Granite Bridge Saw Machine for Stone Slab Cutting Chamfering (HQ700)
Xiamen Aga Import and Export Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Laser Cutting Machine
- Usage：Granite, Marble
- Application：Machinery & Hardware, Stone Industry
- Source Voltage：380V
Base Info
- Model NO.：HQ700
- Automation：Automatic
- Cutting Ability：High Speed
- Control：CNC
- Certification：ISO, CE
- Max. Cut Size (Lxw)：3200X2000 mm
- Max. Cut Thick：230 mm
- Table Tilting：0-85°
- Table Rotation：0-360°
- Blade Tilting：0-45°
- Max. Blade Size：700 mm
- Spindle Motor：18.5 Kw
- Weight：7500kg
- Transport Package：Plastic Packing
- Specification：Dimention: 6 x 5.8 x 3.5 m
- Trademark：AGA
- Origin：Xiamen, Fujian, China
- HS Code：84641010
- Production Capacity：100sets,Month
Description
Advandtage
1. Long brigde structure for cutting big slab.
2. Tilting table for easy load of big slab.
3. Automatic cut by program on PLC system.
4. Precise movements on X, Y, Z axis ensuring cutting accuracy +/-0.2mm.
5. Electric parts from Japan for stability and long service time.
6. Main parts made of cast iron for heavy duty work and stable performance.
- Bridge saw cutting machine for marble granite stones. It is applicable on cutting and trimming slab, countertop, steps, etc.- Blade tilt 45 degree for mitered cuts available for model HQ700
- The table tilts up to 85 for easy load of big slabs and also turns 360 degree to change the cutting direction.
- It is able to cut 3.2m length and 2 m width with laser guide sensor for cutting guide.
- The bridge saw works by industrial computer with programs for automatic cut, and also capable of manual operation. All the operations are achieved from the touch screen panel.
Specification:
| Max. cut size ( L*W ) | mm | 3200 x 2000 |
| Max. cut thick | mm | 230 |
| Table tilting | mm | 0-85 |
| Table size ( L*W ) | ° | 3200 x 2000 |
| Table rotation | ° | 0-360 |
| Blade tilting | ° | 0-45 |
| Max. blade size | mm | Φ700 |
| Spindle motor | Kw | 18.5 |
| Dimention ( L*W*H ) | m | 6 x 5.8 x 3.5 |
Packing
Related bridge saw
Our guarantee & after sale service
AGA insists on equipments high quality and advanced technology to assist customers in their pursuit of a true competitive advance.
1) Warranty for one year. Extra fee is paid if out of date. Any damage to the machine caused by improper use will be charged.
2) When receiving the 30% down payment, we will prepare machine for you, it will take 2-5 weeks, to get the shipping pictures for you.
3) 24-hour technical support Internet or by Telephone, free instructions and Problem solving.
FAQ
1. How to pay to you?
T/T is advance we accept 30% deposit, 70% before shipment
2. How long is the delivery time?
For standard machines, it would be 2-5 weeks; For non-standard machines and customized machines according to client's specific requirements, it would be 10 days longer.
3. Do you arrange shipment for the machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you.
4. How about the documents after shipment?
After shipment, we will send all original documents to you by DHL or Tele-Release, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
5. What is the packing?
a. Water-proof plastic film package with foam protection in each corner
b. Solid Seaworthy Wood Box Package
c. Save space as much as Possible for container loading.
