Machinery Stone Saw Multi Cutter Machine Cutting Block Granite Marble Machines China
Shandong Datang Machinery Technology Co., Ltd.- After-sales Service：Spare Parts
- Warranty：1 Year
- Type：CNC Cutting Machine
- Usage：Granite, Marble
- Application：Machinery & Hardware, Construction, Stone Industry
- Source Voltage：380V
Base Info
- Model NO.：DTQZ
- Automation：Automatic
- Cutting Ability：High Speed
- Control：CNC
- Certification：ISO, CE
- Max. Blade Diameter：2800mm
- Max. Cutting Length：3200mm
- Max. Cutting Height：2200mm
- Max. Cutting Depth：1250mm
- Max. Lifting Stroke：1400mm
- Water Consumption：15m3,H
- Main Motor Power：55kw
- Total Power：66kw
- Dimension：8000*4500*7000mm
- Weight：12500kg
- Transport Package：Nude
- Specification：8000*4500*7000mm
- Trademark：Datang
- Origin：China
- HS Code：8464101000
- Production Capacity：600sets,Year
Description
ModelDTQZ-2200-4DDTQZ-2600-4DDTQZ-2800-4DMax. Blade Size2200mm2600mm2800mmMax. Cutting Length3200mm3200mm3200mmMax. Cutting Height2200mm2200mm2200mmMax. Cutting Depth950mm1150mm1250mmMax. Lifting Stroke1220mm1320mm1400mmWater Consumption15m3/h15m3/h15m3/hMain Motor Power37kW45kW55kWTotal Power48kW56kW66kWDimension7500*4500*6800mm7500*4500*6800mm8000*4500*7000mmWeight11000kg11500kg12500kg
