• Model NO.：PFL
• Finished Surface：Thread Process
• Color：According to You
• Guarantee：One Year
• Certificate：ISO9001:2008, Ce
• Transport Package：Standard Packing
• Specification：ISO9001: 2008
• Trademark：HC
• Origin：Henan China
• Production Capacity：50 Sets,Month

Basic Info.

Model NO. PFL Finished Surface Thread Process Color According to You Guarantee One Year Certificate ISO9001:2008, Ce Transport Package Standard Packing Specification ISO9001: 2008 Trademark HC Origin Henan China Production Capacity 50 Sets/Month

Product Description

Long using life with ISO good quality Vertical Compound Crusher



PFL vertical compound crusher is a new type of machine based on the PCL vertical compound crusher and gets domestic and overseas fine crushing technology into together. It owns the advantages of large crushing ratio, 1.4 times higher than other domestic similar machines; High efficiency and energy-saving; The life of the wearing parts increased 2-3 times; Adjustable gap between hammer and impact plate, which can satisfy different sizes requirement. It is widely used in mining, metallurgy, refractory, cement, coal, glass, ceramics, and electric power industries.

Structure:

The machine has special structure in the part of throw-up disc, which can improve the usage of abrasive material and reduce the cost. The wearing parts are made of anti-abrasion material (metal alloy in high hardness and toughness), so it can endure for long time. It has the advantage of high crushing ratio, large output, high efficiency, and low consumption. It is of easy operation, good performance, low noise, little vibration and good airproofing, so it is a high efficient and high level fine crushing equipment.


The motor drives the rotor that fixed on the main bearing to run quickly toward certain direction when the machine works. The materials are fallen into the throw-up disc and impacted by the high speed strips of the throw-up disc, and then strikes with the impact board under the effect of Centrifugal Force.

Because the impact board is bevel and the gravitation, the materials are threw to the taper crushing room and impacted by the high-rotating up hammerhead. After gaining sufficient energy, the materials are thrown to the impact board again and action repeats. The materials strike with each other in the crushing room and then are down to the column-shape rotor room. Then crushed, pressed, and ground and action repeats. In this way, the materials go through up, middle, and down rotor crushing rooms and crushed, pressed, and ground by the hammers and the impact boards, and finally the materials are gradually crushed into needed sizes and come out.

Type	Main shaft rotating ( r/min )	Feeding size ( mm )	Output size ( mm )	Motor power ( kw )	( t/h )	Overall dimensions (L×W×H) ( mm )
PFL-800	1000	< 50	< 3-5 60-90%	15-22	10-20	2100×1200×1700
PFL-1000	750	< 120	< 3-5 60-90%	37-55	20-45	2600×1400×1900
PFL-1250	530	< 150	< 3-5 60-90%	55-75	40-70	2800×1600×2100
PFL-1500	495	< 120	< 3-5 60-90%	132	70-100	3100×1900×2200
PFL-1750	424	< 120	< 3-5 60-90%	160	130-190	3710×2360×2390
PFL-2000	370	< 120	< 3-5 60-90%	185	100-160	4100×2660×2620
