Multi Blade Automatic Marble Granite Cutting Machine for Natural Stone

Shandong Datang Machinery Technology Co., Ltd.
  • After-sales Service：Spare Parts
  • Warranty：1 Year
  • Type：CNC Cutting Machine
  • Usage：Granite, Marble
  • Application：Machinery & Hardware, Construction, Stone Industry
  • Source Voltage：380V

Base Info

  • Model NO.：DTQZ
  • Automation：Automatic
  • Cutting Ability：High Speed
  • Control：CNC
  • Certification：ISO, CE
  • Max. Blade Diameter：2800mm
  • Max. Cutting Length：3200mm
  • Max. Cutting Height：2200mm
  • Max. Cutting Depth：1250mm
  • Max. Lifting Stroke：1400mm
  • Water Consumption：15m3,H
  • Main Motor Power：55kw
  • Total Power：66kw
  • Dimension：8000*4500*7000mm
  • Weight：12500kg
  • Transport Package：Nude
  • Specification：8000*4500*7000mm
  • Trademark：Datang
  • Origin：China
  • HS Code：8464101000
  • Production Capacity：600sets,Year

Description

ModelDTQZ-2200-4DDTQZ-2600-4DDTQZ-2800-4DMax. Blade Size2200mm2600mm2800mmMax. Cutting Length3200mm3200mm3200mmMax. Cutting Height2200mm2200mm2200mmMax. Cutting Depth950mm1150mm1250mmMax. Lifting Stroke1220mm1320mm1400mmWater Consumption15m3/h15m3/h15m3/hMain Motor Power37kW45kW55kWTotal Power48kW56kW66kWDimension7500*4500*6800mm7500*4500*6800mm8000*4500*7000mmWeight11000kg11500kg12500kg
