• Model NO.：PE series
• Finished Surface：Hole Process
• Certification：CE, ISO
• Condition：New
• Color：Iron Grey
• Spare Parts Supply：for Whole Year
• After-Sale Service：for Whole Using Year
• Test&Installation：Engineer Assigned
• Export Markets：Global
• Transport Package：Container, Nude Packs, in Bulk
• Specification：ISO9001: 2000
• Trademark：Zenith
• Origin：China
• HS Code：8474209000
• Production Capacity：40-850tph

Basic Info.

Model NO. PE series Finished Surface Hole Process Certification CE, ISO Condition New Color Iron Grey Spare Parts Supply for Whole Year After-Sale Service for Whole Using Year Test&Installation Engineer Assigned Export Markets Global Transport Package Container, Nude Packs, in Bulk Specification ISO9001: 2000 Trademark Zenith Origin China HS Code 8474209000 Production Capacity 40-850tph

Product Description

Zenith Hot Sale Hard Rock Crusher with Large Capacity

Zenith jaw crushers are ideally suitable for primary and secondary crushing, with Low power consumption and easy maintenance. Every feature of these machines has Been carefully designed to provide superior quality and performance. They are widely Used for crushing various materials like stone, granite, trap rock, coke coal, manganese ore, iron ore, emery, fused aluminum, oxide, fused calcium carbide, lime stone, quartzite, alloys, etc. These crushers are recommended by leading consultants in this field and are used by hundreds of customers all over the world.





Jaw Crusher Features:

1) The jaw crusher has various types available

2) Easy to operate

3) This jaw crusher is suitable for crushing maximum, medium and minimum stones

4) The structure of jaw crusher includes main frame, main axle, roller bearings,
Eccentric shaft, jaw plates, side plates, toggle mechanism, fly wheels and springs

5) Zenith jaw crushers are ideally suitable for primary and secondary crushing,
with low power consumption and easy maintenance

6) They are widely used for crushing various materials like stone, granite, trap rock, coke, coal, manganese ore, iron ore, emery, fused aluminum, oxide, fused calcium carbide, lime stone, quartzite, and alloys.

Model	Feeder Opening (mm)	Setting Adjustment Range (mm)	Max. Feeding Size (mm)	Capacity (t/h)	Motor Power (KW)	Weight (t)	Overall Dimension (mm)
PE500x750	500x750	50-100	425	40-110	45-55	12	2035x1921x2000
PE600x900	600x900	65-160	480	90-180	55-75	17	2290x2206x2370
PE750x1060	750x1060	80-140	630	110-320	90-110	29	2655× 2302× 3110
PE900x1200	900x1200	95-165	750	220-450	110-132	52	3200× 3050× 2950
PE1000x1200	1000x1200	195-265	850	315-550	110-132	57	3800× 3166× 3045
PE1200x1500	1200x1500	150-300	950	400-850	220	82.5	4200× 3750× 3820
