Huada Diamond Wire Saw Machine with Permanent Magnet Motor, The Newest Diamond Wire Saw
Huada Superabrasive Tool Technology Co., Ltd.- Usage：Concrete Curb, Granite, Marble
- Application：Machinery & Hardware, Construction, Stone Industry
- Source Voltage：380V
- Automation：Automatic
- Cutting Ability：High Speed
- Certification：CE
Base Info
- Model NO.：PM DWS
Description
Reinforced Type for Granite
Model
Main Motor Power
Length of Wire
(m)
Line Speed
(m/s)
Remark
DWS-22AX-6PG
22KW
5-40
0-30
used for block cutting
DWS-37AX-8PG
37KW
20-80
0-30
used for quarrying
DWS-55AX-8PG
55KW
20-120
0-30
DWS-75AX-10PG
75KW
20-150
0-30
Reinforced Type for Marble
Model
Main Motor Power
Length of Wire
(m)
LinearSpeed
(m/s)
Remark
DWS-22AX-4PG
22KW
5-40
0-40
used for block cutting
DWS-37AX-6PG
37KW
20-80
0-40
used for quarrying
DWS-55AX-6PG
55KW
20-120
0-40
DWS-75AX-8PG
75KW
20-150
0-40
2. Diamond Wire Saw machine with permanent magnet power.
Especially suitable for the safe use under wide voltage variation conditions to meet the unique quarrying needs of different customers.
Constant torque output in full frequency range, especially its high pulling torque at low frequency, ensures easy start of machine, more energy saving and environment friendly.
Less power consumption allows the deployment of more DWS's in the same quarry site WITHOUT restructuring the power supply system
We found the first Quarry Mining Institute in China
