Rock Driller for Stone, Two Hammer, Vertical and Horizontal Drilling
Huada Superabrasive Tool Technology Co., Ltd.- Type：Stone Drilling Machine
- Drill Direction：Vertical
- Depth of Drilling：0-100 M
- Drilling Speed：0-50 M,H
- Automation：Automatic
- Layout：Horizontal and Vertical
Base Info
- Model NO.：CZH-24,29-2B
- Control：Air Compressor Driven
- Precision：Normal Precision
- Application：Stone Industry
- Certification：ISO, CE
- Export Markets：Global
- Transport Package：Plywood
- Specification：high quality, SGS
- Trademark：HUADA
- Origin：Quanzhou, Fujian, China
- Production Capacity：100 Set Per Month
Description
Rock Driller
CZH-29-2A
Model
2-YT29A
Rated track length
2*3m
Max. drilling depth
6m
Drilling diameter
34mm-42mm
Min.air pressure
0.5-0.7MPa
Drilling speed
2*30m/h
Total compressed air consumption
10m3/min
Track travel
2m
Advance device
Pneumatic motor , chain
Cross travel device
gear , rack
Drilling direction
Any direction
Number of the hole hammer
2
Total weight
1000kg
