• Model NO.：PEW250x1200, PEW400x600, PEW760, PEW860
• Finished Surface：Hole Process
• Certification：CE, ISO, GOST
• Condition：New
• Color：Iron Grey
• Spare Parts Supply：for Whole Year
• After-Sale Service：for Whole Using Year
• Test&Installation：Engineer Assigned
• Export Markets：Global
• Transport Package：Container, Nude Packs, in Bulk
• Specification：CE, ISO
• Trademark：Zenith
• Origin：Shanghai Zenith, China
• HS Code：8474209000
• Production Capacity：40-850tph

Basic Info.

Model NO. PEW250x1200, PEW400x600, PEW760, PEW860 Finished Surface Hole Process Certification CE, ISO, GOST Condition New Color Iron Grey Spare Parts Supply for Whole Year After-Sale Service for Whole Using Year Test&Installation Engineer Assigned Export Markets Global Transport Package Container, Nude Packs, in Bulk Specification CE, ISO Trademark Zenith Origin Shanghai Zenith, China HS Code 8474209000 Production Capacity 40-850tph

Product Description

2017 hot sale high efficient fine impact crusher

high efficient fine impact crusher Application

It's widely used for high efficient fine impact crusher, cement clinker, mixed materials, shale, dolomite, gypsum and other medium hardness materials in cement, coal dressing, heat power station, metallurgy, fire-proof materials and other industries. As a professional impact crusher manufacturer, We choose the best materials to build the plates and best technology to meet the customers' need.


high efficient fine impact crusher features and benefits:

1. High reduction ratio and crushing efficiency;
2. No-board connection; The blow bar with high chrome(high chromed blow bar).
3. Impact plate with a special shape.
4. Crushed product with cubical shape.
5. Easy maintenance and reliable operation.

high efficient fine impact crusher Characteristics:

Hammer is made of high chrome; Liner board is made of wearable materials;
Specially designed tooth impact plate;
More suitable for crushing hard rock, high efficiency, low consumption;
Final products is cubic, discharge opening is adjustable;
Make the crushing flow chart simple.

high efficient fine impact crusher parameters:

Model	Rotor Φ×L (mm)	Feed Opening (mm)	Max Feeding (mm)	Capacity (t/h)	Power (kw)	Motor Model	Machine Size (mm)
PFW1214II	Φ1150×1400	1100×1430	500	130-200	4-132	Y315M-4/132	2400×2310×2550
PFW1315II	Φ1300×1500	1200×1530	600	180-320	4-160	Y315L1-4/160	2700×2570×2800
PFW1318II	Φ1300×1800	1200×1830	700	240-400	4-200	Y315L2-4/200	2700×2870×2800
PFW1415II	Φ1400×1500	1450×1530	800	240-450	4-200	Y315L2-4/200	3000×2700×3070
