1200mm Blade Bridge Type Stone Saw for Sale Granite Slab Cutting Machine

Shandong Datang Machinery Technology Co., Ltd.
  • Warranty：1 Year
  • Type：CNC Cutting Machine

Base Info

  • Model NO.：DTQ
  • Usage：Concrete Curb, Granite, Marble
  • Application：Machinery & Hardware, Construction, Stone Industry
  • Source Voltage：380V
  • Automation：Automatic
  • Cutting Ability：High Speed
  • Control：CNC
  • Certification：ISO, CE
  • Max. Cutting Size：3200*2000*275mm
  • Blade Size：400-800mm
  • Work Table Size：3200*2000mm
  • Work Table Tilting：0-85 Degrees
  • Work Table Rotating：0-90,0-360 Degrees
  • Main Motor Power：18.5kw
  • Water Consumption：3.5m3,H
  • Dimension：6000*4800*3300mm
  • Weight：10650kg
  • Transport Package：Nude
  • Specification：6000*4800*2600mm
  • Trademark：Datang
  • Origin：China
  • HS Code：8464109000
  • Production Capacity：600sets,Year

Description

ModelDTQ-450DTQ-600DTQ-700DTQ-800Max. Cutting Size3200*2000*100mm3200*2000*175mm3200*2000*225mm3200*2000*275mmBlade Size400-450mm400-600mm400-700mm400-800mmWork Table Size3200*2000mm3200*2000mm3200*2000mm3200*2000mmWork Table Tilting0-85 degrees0-85 degrees0-85 degrees0-85 degreesWork Table Rotating0-90/0-360 degrees0-90/0-360 degrees0-90/0-360 degrees0-90/0-360 degreesMain Motor Power15kW18.5kW18.5kW18.5kWWater Consumption3.5m3/h3.5m3/h3.5m3/h3.5m3/hDimension6000*4800*2600mm6000*4800*2800mm6000*4800*3150mm6000*4800*3300mmWeight8700kg9200kg10500kg11000kg
