• Model NO.：KE series
• Crushing Style：Grinding & Impact
• Compressive Strength (For Crushing)：>300MPA
• Crushing Degree：Intermediate Crusher
• Finished Surface：Hole Process
• Certification：CE, ISO, GOST
• Condition：New
• Color：Iron Grey
• Spare Parts Supply：for Whole Year
• Test&Installation：Engineer Assigned
• After-Sale Service：for Whole Using Life
• Export Markets：Global
• Transport Package：Container, Nude Packs, in Bulk
• Specification：ISO9001: 2000
• Trademark：Zenith
• Origin：China
• HS Code：8474209000
• Production Capacity：80sets,Month

Basic Info.

Model NO. KE series Crushing Style Grinding & Impact Compressive Strength (For Crushing) >300MPA Crushing Degree Intermediate Crusher Finished Surface Hole Process Certification CE, ISO, GOST Condition New Color Iron Grey Spare Parts Supply for Whole Year Test&Installation Engineer Assigned After-Sale Service for Whole Using Life Export Markets Global Transport Package Container, Nude Packs, in Bulk Specification ISO9001: 2000 Trademark Zenith Origin China HS Code 8474209000 Production Capacity 80sets/Month

Product Description

ISO certification mobile stone crushing machine, portable rock crusher on trailer

portable rock crusher on trailer introduction:

portable rock crusher on trailer has the advantages of easy transportation, low transportation cost, flexible configuration, convenient maintenance etc. It can be operated as independent units, or as two-stage crushing plant with primary and secondary crushing, or as three stage crushing plant with primary, secondary, and tertiary crushing according to different clients' requirements. Likewise, it can be easily adjusted to suit the crushing application by choosing feeding to crusher or feeding to screen options.

portable rock crusher on trailer  is developed according to novel series stone crushing equipment's design idea, which expands the concept field of coarse crushing and fine crushing. Its design idea is based on the client's requirements, which clears faults of the crushing place, surroundings and the complex basic configurations. This series mobile coal crusher really supply simpler, higher efficient and lower cost machine for clients.
large portable rock crusher on trailer breaks through the constraint of traditional fixed crushing plants and its high transportation cost. It can deal with materials in nearby site which is widely applied in mining, metallurgy, building material, transportation, water conservancy and other industries. Mobile crusher concept is fully adaptable to all mobile crushing demands; It sets up a new range of business opportunities for contractors, quarry operators, recycling and mining applications. Vipeak mobile coal crusher can eliminate the area of the crushing site, and offer high efficient & low cost project plants for the client. The incorporated setting is easy to maintain and install which makes the mobile crusher plant have long endurance and higher efficiency. There are two types of mobile crusher: Wheeled type mobile crusher and crawler type mobile crusher. Wheeled type mobile crusher is also called tire type mobile crusher, tyre type mobile crusher, rubber-tyre type mobile crusher; Crawler type mobile crusher is also called tracked type mobile crusher, track-mounted type mobile crusher. The mobile crusher manufacturers is usually called mobile crushing plant, mobile crusher station or portable crusher.

portable rock crusher on trailer manufacturers

Feeder, belt conveyor and vibrating screen are all in one vehicle.
Turn axle of traction is convenient for road transit and expanding the working place.
Vehicle installation supporting is easier for equipment to station in the working place.
Vehicle electric generating set, motors and control box are all included.

Characteristics of portable rock crusher on trailer

1.Flexibility;
2.Lower freight cost;
3.Direct and efficient operation;
4.Easy to adapt and flexible to collocate;
5.Reliable performance and convenient maintenance.

portable rock crusher on trailer parameters:

Model	Specs. of screening equipment	Specs. of crushing equipment	Specs. of main belt conveyor	Hopper volume(m3)	Max.feeding size (mm)	Transportation dimension(mm)
KE600-1	TSW0936	PE600×900	B800×8.3m	5.3	500	12150×2600×3950
KE750-1	TSW1139	PE750×1060	B1000×8.5m	7	630	13000×2850×4400
KE760-1	TSW1139	PEW760	B1000×8.5m	7	640	13000×2800×4200
KE860-1	TSW1345	PEW860	B1200×9.5m	8	720	14600×3000×4500
KE1100-1	TSW1548	PEW1100	B1400×9.5m	11	930	14050×2900×4000
KJ98-1	TSW1139	HJ98	B800×8.3m	5.9	560	12150×2600×3950
KJ110-1	TSW1345	HJ110	B1000×8.5m	8.5	660	13200×3000×4400
KJ125-1	TSW1345	HJ125	B1400×9.5m	8	800	14600×3000×4500
KF1214-1	TSW0936	PFW1214	B800×8.3m	5.3	500	12150×2600×3980
KF1315-1	TSW1345	PFW1315	B1200×9.5m	8	600	14600×3100×4500
KF1415-1	TSW1548	PFW1415	B1200×9.5m	11	700	14050×3000×4000
