Single Blade Machine Price for Granite Marble Slab Block Tiger Stone Cutting

Shandong Datang Machinery Technology Co., Ltd.
  • Warranty：1 Year
  • Type：CNC Cutting Machine

Base Info

  • Model NO.：DTQD
  • Usage：Granite, Marble
  • Application：Machinery & Hardware, Construction, Stone Industry
  • Source Voltage：380V
  • Automation：Automatic
  • Cutting Ability：High Speed
  • Control：CNC
  • Certification：ISO, CE
  • Blade Size：2600mm
  • Max. Cutting Length：4800mm
  • Max. Lifting Stroke：1300mm
  • Work Table Size：2000*2000mm
  • Main Motor Power：37kw
  • Feed Motor Power：2.2kw
  • Total Power：42.25kw
  • Water Consumption：8m3,H
  • Dimension：6300*5150*7100mm
  • Weight：8500kg
  • Transport Package：Nude
  • Specification：6220*5150*7100mm
  • Trademark：Datang
  • Origin：China
  • HS Code：8464101000
  • Production Capacity：600sets,Year

Description

ModelDTQD-1800DTQD-2200DTQD-2600DTQD-3000Blade Size1800mm2200mm2600mm3000mmHorizontal Stroke3500mm3600mm3700mm3800mmLifting Stroke1150mm1150/1300mm1400mm1500mmBeam Length6000mm6500mm7000mm7500-9500mmSlide Plate Length2000mm2000/2150mm2250mm2350mmMain Motor Power30kW37kW37kW37kWFeed Motor Power1.5kW1.5kW2.2kW2.2kWHydraulic Station Power3kW3kW4kW4kWWater Consumption6m3/h7m3/h9m3/h10m3/hTrolley Size1700*1700mm1700*1700mm1700*1700mm1700*1700mmTrolley Rail Distance1400mm1400mm1400mm1400mmTrolley Rail Length5000mm5000mm5000mm5000mmDimension5220*5150*5210mm5720*5150*6000mm6220*5150*7100mm6720*5150*5800mmWeight7000kg7500kg8500kg9000kg
