Sand Making Crusher Price, Cone Crusher (CPYQ)

Chemact (Liaoning) Petrochemicals Ltd.
  • Type:Cone Crusher
  • Application:Machinery & Hardware, Art & Craft, Chemical, Construction, Mineral Industry, Stone Industry
  • Drive:Electric
  • Crushing Style:Grinding & Impact
  • Compressive Strength (For Crushing):<300mpa
  • Crushing Degree:Fine Grinding Machine

Base Info

  • Model NO.:CPYQ
  • Finished Surface:Cut Off Tool
  • Certification:CE, ISO, GOST, SONCAP, UL, CCC, API
  • Condition:New
  • Color:Red
  • Power(W):500-600(Kw)
  • Capacity(T/H):780-1250
  • Place of Origin:Shanghai, China (Mainland)
  • Brand Name:Chuangshen
  • Model Number:Cpyq 1839
  • Dimension(L*W*H):3452*3580*5007
  • Weight:Negotiable
  • Warranty:Mainframe Is One Year (Excluding The Quick Wear PA
  • After-Sales Service Provided:Engineers Available to Service Machinery Overseas
  • Transport Package:Standard Packaging
  • Specification:Industrial grade
  • Trademark:shanghai
  • Origin:Shanghai China

Description

Basic Info.

Model NO. CPYQ Finished Surface Cut Off Tool Certification CE, ISO, GOST, SONCAP, UL, CCC, API Condition New Color Red Power(W) 500-600(Kw) Capacity(T/H) 780-1250 Place of Origin Shanghai, China (Mainland) Brand Name Chuangshen Model Number Cpyq 1839 Dimension(L*W*H) 3452*3580*5007 Weight Negotiable Warranty Mainframe Is One Year (Excluding The Quick Wear PA After-Sales Service Provided Engineers Available to Service Machinery Overseas Transport Package Standard Packaging Specification Industrial grade Trademark shanghai Origin Shanghai China

Product Description

single cylinder hydraulic cone crusher price,Top 10 chinese brands cone crusher for sale

I.CPYQ single cylinder hydraulic  stone crushers

Single cylinder hydraulic cone crushers are developed by introduction of foreign technology and widely applied in mining, metallurgy and building material industries. They can crush ores and rocks with various hardness even the most hardness. CPY Series have simple structure, excellent productivity, low energy consumption and even product size.



II. CPYQ single cylinder hydraulic  stone crushers are appropriate for

1.use situation versatility
2.ores and rocks with various hardness
3.concrete basis and steel structure basis
4.stationary, half-mobile and mobile application

III. Main advantages of   CPYQ single cylinder hydraulic  stone crushers

1.CPYQ Single cylinder hydraulic cone crusher is made by Japanese technology. The machine uses laminated crushing principle, one cylinder replace the traditional hydraulic spring protection, and lubricates.

2.No packing liner, rapid for replacement and reduced downtime.

3.Material level detection device can automatically remove the excess material; CPYQ-1212 got the device, can be evenly feeding.

4. Discharge opening with hydraulic adjustment makes it quick and easy.

5. Transmission with arc-shape gear gives stronger power and lighter noise.

6.Blowing dust system on the top gives longer lives of all bronze bushing`s spare parts.

7.Cooling mode of oil lubrication system flexible and extensive district use.

8. Single cylinder hydraulic cone crushers have sided cone and different eccentricity to fit for different customers. Simple construction contributes to easy maintenance. High accuracy parts can satisfy reliability and stability in long-time running.

Sand Making Crusher Price, Cone Crusher (CPYQ)
Sand Making Crusher Price, Cone Crusher (CPYQ)
ModelDiameter Of Crushing Cone
(mm)
Feed Opening Size
(mm)
Max Feed Size
(mm)
Discharging Size
(mm)
Capacity
(t/h)
Power
(kw)
Overall Dimensions
(LxWxH)(mm)
CPYQ-090890080654-1227-4890-1321955x1876x2846
CPYQ-09129001201008-1538-5590-1321955x1876x2846
CPYQ-091890018015010-2542-8090-1321955x1876x2846
CPYQ-092590025021020-4065-18090-1321955x1876x2846
CPYQ-121212001201006-15120-185160-2202335x2732x3253
CPYQ-1216120016013510-20160-220160-2202335x2732x3253
CPYQ-1224120024020515-25200-250160-2202335x2732x3253
CPYQ-1232120032027025-40260-335160-2202335x2732x3253
CPYQ-1515150015012510-20230-370315-4502952x3080x4607
CPYQ-1525150025021015-25350-465315-4503100x2900x4557
CPYQ-1533150033028025-40470-650315-4503100x9000x4557
CPYQ-1541150041035040-55650-780315-4503100x2900x4607
CPYQ-1818180018015010-25390-610500-6003452x3580x5007
CPYQ-1828180028023519-38450-800500-6003452x3580x5007
CPYQ-1839180039033032-55780-1250500-6003452x3580x5007
CPYQ-1847180047040038-64820-1460500-6003452x3580x5007
