Hydraulic Edgestone Split Machine for Natural Face
Xiamen Bestlink Factory Co., Ltd.- Type：Hydraulic Cutting Machine
- Usage：Fire Brick, Concrete Curb, Granite, Marble
- Application：Construction, Mineral Industry, Stone Industry
- Source Voltage：380V
- Automation：Semi-automatic
- Cutting Ability：Medium Speed
Base Info
- Model NO.：BRT20-BRT40-BRT70-BRT160-320T Split Machine
- Control：Artificial
- Certification：CE
- Max Splitting Height：800mm
- Max Splitting Width：1200mm
- Color：Green and Blue, Other Color Available
- Key Word：Cube Stone Castle Stone, Fieldstone, Ledgestone Cut
- Tons Type：From 20ton to 320tons.
- Main Market：Global Market
- Trade Way：Own Factory Made at Xiamen
- Certificate：Ce&ISO2000&SGS
- Driven Force：Hydraulic Pump
- Export Experience：10 Years
- Transport Package：Plywood Packing
- Specification：CE&SGS
- Trademark：BESTLINK
- Origin：Xiamen China
- HS Code：84791090
- Production Capacity：100sets,Year
Description
Bridge Type / Closed TypeModel No. BRT320T-1200*800-MBRT200T-1200*400-MBRT160T-1000*400-MBRT120T-1000*300-MBRT70T-800*300-MBRT40T-600*200-MMax splitting forceTon3202001601207040Max splitting widthmm1200120010001000800600Max splitting heightmm800400400300300200Single blade sizemm194*50*40194*50*40194*50*40194*50*40160*40*25160*40*25Blade QTY.pcs484840404032Adaptation of upper/lower blademm36*2030*1530*1520*1020*1020*10Power supplyKW22151515117.5Main oil cylinder datammΦ400/Φ280-800Φ320/Φ200-400Φ280/Φ200-400Φ280/Φ200-300Φ220/Φ140-300Φ180/Φ120-200Bench heightmm900900900900900900Machine overall size(L*W*H)mm2370*1500*38402010*1240*28551810*1240*28551780*1140*25751570*1140*24901390*1140*2300Machine weightkg1000085004800400030002200Hydraulic unit sizemm1280*1000*14751280*1000*14751280*1000*13451280*1000*1345960*650*1220800*650*1100Hydraulic unit weightkg600600550550400310
