Stone Edge Cutting Machine Marble Granite Line Process

FUJIAN NAN'AN HENGLONG MACHINERY CO.,LTD.
  • After-sales Service：Provide
  • Warranty：1year
  • Type：CNC Cutting Machine
  • Usage：Ceramics, Cement Brick, Granite, Marble
  • Application：Machinery & Hardware, Construction, Mineral Industry, Stone Industry
  • Source Voltage：380V

Base Info

  • Model NO.：HLFQ-3000
  • Automation：Automatic
  • Cutting Ability：High Speed
  • Control：CNC
  • Blade Size：350-600mm
  • Max.Working Dimension：3000*1150*600mm
  • Max.Cutting Thickness：180mm
  • Cutting Speed：0-7500mm,Min
  • Main Motor Power：15kw
  • Water Consumption：4 M3,H
  • Gross Weight：4800kg
  • Specification：5000*2200*2400m
  • Trademark：Henglong
  • Origin：Fujian, China
  • HS Code：84641090
  • Production Capacity：30~50sets ,Month

Description

Basic Info.

Model NO. HLFQ-3000 Automation Automatic Cutting Ability High Speed Control CNC Blade Size 350-600mm Max.Working Dimension 3000*1150*600mm Max.Cutting Thickness 180mm Cutting Speed 0-7500mm/Min Main Motor Power 15kw Water Consumption 4 M3/H Gross Weight 4800kg Specification 5000*2200*2400m Trademark Henglong Origin Fujian, China HS Code 84641090 Production Capacity 30~50sets /Month

Product Description

Stone Edge Cutting Machine Marble Granite Line Process
Stone Edge Cutting Machine Marble Granite Line Process
Stone Edge Cutting Machine Marble Granite Line Process
Stone Edge Cutting Machine Marble Granite Line Process


Product description

This machine works by Computer, Auto Tracking, Exact Shape Copy
It is designed to carry out architectural shaping such as profile, roman column and other diverse shapes on granite marble.

Technical Parameters
-Max. cutting dimension: 3000x1150x600mm(LxWxH)
-Max. cutting depth: 180mm
-Blade diameter: 350-600mm,
-Cutting speed: 0-7500 mm/min,
-Main motor power: 15kw,
-Water consumption: 4 m3/h,
-Overall dimension: 5000x2200x2400mm(LxWxH),
-Total weight: 4800kg.


For more, please feel free to contact us.
