• Model NO.：Huada Wire Saw DWS-110AX-8P
• Automation：Automatic
• Cutting Ability：High Speed
• Control：Electrical Driven
• Certification：ISO, CE
• Motor：110kw(150HP)
• Transport Package：Plywood Packing
• Specification：CE, ISO
• Trademark：HUADA
• Origin：Quanzhou, Fujian, China
• Production Capacity：100 Set Per Month

Model
Main Motor Power
Length of Wire
(m)
LinearSpeed
(m/s)
Remark
DWS-37AX-6P
37KW
20-80
0-40
Used for quarrying
DWS-45AX-6P
45KW
20-100
0-40
DWS-55AX-6P
55KW
20-120
0-40
DWS-75AX-8P
75KW
20-150
0-50
DWS-90AX-8P90KW20-1500-50DWS-110AX-8P110KW20-1500-50
Features:

1.Controlled by dual inverter+PLC,make the diamond wire saw strain constantly and the speed of moving truck automatically controlled.
2.When under the automatic control state,the machine can track changes in the load so as to make the diamond wire saw work efficiently all the time by adjusting the move speed of the machine.
3.Can protect the diamond wire saw from break,overload,lack of phase,terminal limit.
4.Have the easy-operating functions of electric turnover,electric horizontal movement and quick moving.

Rubber/Spring Diamond Wire Saw for Marble/Limestone Quarry

As soft stone, marble mostly consists of calcium carbonate, and dolomite, barely no quartz or feldspar. Spring diamond wire is a cost-effective tool that is widely used for marble quarry.  Meanwhile, as more attention is paid to the safety of operators, rubber wire is also gaining popularity in marble quarry.
