Large Capacity Cone Crusher by Audited Supplier
Shanghai Clirik Machinery Co., Ltd.- After-sales Service：1 Year
- Warranty：Technical Support
- Type：Cone Crusher
- Application：Machinery & Hardware, Chemical, Construction, Mineral Industry, Stone Industry
- Drive：Hydraulic
- Crushing Style：Grinding & Impact
Base Info
- Model NO.：PYD, PYB, PYZ
- Compressive Strength (For Crushing)：>300MPA
- Crushing Degree：Coarse Crusher
- Finished Surface：Gear Process
- Certification：CE, ISO, SGS
- Condition：New
- Color：Customized
- Cone Crusher Color：as Request
- Cone Crusher Warranty：1 Year
- Cone Crusher After Sales：Engineers Abroad Available
- Cone Crusher Installation：Enginners Guide
- Cone Crusher Max Feed Size：145 Mm
- Cone Crusher Power：55-280 Kw
- Cone Crusher Capcity：50-340 T,H
- Cone Crusher Diameter：900-2200 Mm
- Cone Crusher Output Size：5-50mm
- Cone Crusher Rotation：220-330 R,Min
- Transport Package：Moistureproof, Antirust, Seaworthy
- Specification：CE, SGS, ISO9001
- Trademark：clirik
- Origin：Shanghai, China
- HS Code：84742090
- Production Capacity：80 Sets Per Month
Description
ModelMovable Cone Diameter mm (inch) Chamber Style Opening Side Closed Side Discharging Opening
(mm) REV (r/min) Power (kw) Motor Model Capacity (t/h) Machine Size (mm) Max.Feeding
(mm) CSB75 900 (3') Medium 83 102 9-22 580 6-75 Y315S-6/75 45-91 2821×1880 ×2164 Coarse 159 175 13-38 59-163 CSD75 914 (3') Fine 13 41 3-13 580 6-75 Y315S-6/75 27-90 2821×1880 ×2410 Medium 33 60 3-16 27-100 Coarse 51 76 6-19 65-140 CSB160 1295 (4 1/4') Fine 109 137 13-31 485 6-185 Y355M2-6/185 109-181 2800×2342 ×2668 Medium 188 210 16-31 132-253 Coarse 216 241 19-51 172-349 CSD160 1295 (4 1/4') Fine 29 64 3-16 485 6-160 Y355M1-6/160 36-163 2800×2342 ×2668 Medium 54 89 6-16 82-163 Coarse 70 105 10-25 109-227 CSB240 1650 (5 1/2') Fine 188 209 16-38 485 6-240 181-327 3911×2870 ×3771 Medium 213 241 22-51 258-417 Coarse 241 268 25-64 299-635 CSD240 1650 (5 1/2') Fine 35 70 5-13 485 6-240 90-209 3917×2870 ×3771 Medium 54 89 6-19 136-281 Coarse 98 133 10-25 190-336 CSB400 2134 (7') Fine 253 278 19-38 435 6-400 381-726 5200×4300 ×4700 Medium 303 334 25-51 608-998 Coarse 334 369 31-64 870-1400 CSD400 2134 (7') Fine 51 105 5-16 435 6-400 190-408 5200×4300 ×4700 Medium 95 133 10-19 354-508 Coarse 127 178 13-25 454-599
Services to be enjoyed when purchasing grinding equipment:Any inquiries of our products will be highly regard and we will give you the best quotation ASAP. Your satisfaction is our final ann forever pursuit.
Please fill in your need products and your message and do not forget email and/or phone if you like to be contacted.
We look forward to your inquiries!
