CNC Control System Marble Block Granite Profile Processing Cutting Machine
Shandong Datang Machinery Technology Co., Ltd.- Warranty：1 Year
- Type：CNC Cutting Machine
Base Info
- Model NO.：DTSJ
- Usage：Granite, Marble
- Application：Machinery & Hardware, Construction, Stone Industry
- Source Voltage：380V
- Automation：Automatic
- Cutting Ability：High Speed
- Control：CNC
- Certification：ISO, CE
- Diamond Wire Diameter：8-11mm
- Diamond Wire Length：21350mm
- Cutting Wire Speed：0-40m,S
- Lifting Stroke：2200mm
- Max. Processing Size：4000*2000*2100mm
- Productivity：1-2m2,H Marble, 0.5-1m2,H Granite
- Work Table Rotation：360 Degrees
- Total Power：20.09kw
- Dimension：9800*7000*5200mm
- Weight：15000kg
- Transport Package：Nude
- Specification：7500*6000*3800mm
- Trademark：Datang
- Origin：China
- HS Code：8464102000
- Production Capacity：300sets,Year
Description
ModelDTSJ-1500DTSJ-1800DTSJ-2200Diamond Wire Diameter8-11mm8-11mm8-11mmDiamond Wire Length16500mm18500mm21350mmCutting Wire Speed0-40m/s0-40m/s0-40m/sLifting Stroke1600mm1900mm2200mmWork Table Rotation360 degrees360 degrees360 degreesMax. Processing Size3000*2000*1500mm3600*2000*1800mm4000*2000*2100mmProductivity1-2m2/h Marble
0.5-1m2/h Granite1-2m2/h Marble
0.5-1m2/h Granite1-2m2/h Marble
0.5-1m2/h GraniteTotal Power15.09kW15.09kW20.09kWDimension7500*6000*3800mm8800*6800*4800mm9800*7000*5200mmWeight7500kg9500kg15000kg
0.5-1m2/h Granite1-2m2/h Marble
0.5-1m2/h Granite1-2m2/h Marble
0.5-1m2/h GraniteTotal Power15.09kW15.09kW20.09kWDimension7500*6000*3800mm8800*6800*4800mm9800*7000*5200mmWeight7500kg9500kg15000kg
