• Model NO.：HLLD-2800,3500
• Automation：Automatic
• Cutting Ability：High Speed
• Control：Artificial
• Certification：SONCAP, ISO, CE
• Power of Main Motor：55-75kw
• Saw Blade Diameter：2800-3500mm
• Cutting Length：3500mm
• Cutting Width：2300mm
• Lifting Stroke：1400-1450mm
• Total Power：67-87kw
• Gross Weight：12500-18000kg
• Transport Package：Staandard
• Specification：7800*4500*4500-7800*4500*4800
• Trademark：hl&sm
• Origin：Shuitou Xiamen China
• Production Capacity：2600sets,Year

Basic Info.

Model NO. HLLD-2800/3500 Automation Automatic Cutting Ability High Speed Control Artificial Certification SONCAP, ISO, CE Power of Main Motor 55-75kw Saw Blade Diameter 2800-3500mm Cutting Length 3500mm Cutting Width 2300mm Lifting Stroke 1400-1450mm Total Power 67-87kw Gross Weight 12500-18000kg Transport Package Staandard Specification 7800*4500*4500-7800*4500*4800 Trademark hl&sm Origin Shuitou Xiamen China Production Capacity 2600sets/Year

Product Description

HLLD-2800/3500
Heavy size bridge type block cutting machine
1. This machine uses inverter to control left-right feeding and adjusts speed according to the stone material. It uses hydtaulic lifting system, combination of chrome-plated guide pin and wear guide bush with small gap,wearable,beautiful structure. The guide sleeve with multi-layer seals with waterproof,dustproof,anti-spill, improving the service life. Foeward-backward slicing uses high-precision screw nut driving, qutonatic slicing, main spare parts adopt imported good quality materials, the blodk can be place on the ground directly to enconomize the worktable and maintance costs; Thus the whole machine is featured by it's high cutting efficiency, high slicing precision, flatness of plate after cutting, high stability, easy-operating to suit granite and marble block with high value.
