• Model NO.：PE600*900
• Finished Surface：Cut Off Tool
• Certification：CE, ISO, SGS
• Condition：New
• Color：Red
• Name：PE750*1060
• Weight(T)：29
• Motor Power(Kw)：90-110
• Capcity(T/H)：110-320
• Size of Feeder Opening(mm)：750*1060
• Max. Feeding Size(mm)：630
• Size of Output(mm)：80-140
• Installation：Under The Guidance of Engineer
• After-Sale Service：Training, Technical Support, etc.
• Mining Object：Metallic and Non-Metallic Ore Excavator
• Transport Package：International Packing Standard
• Specification：750*1060mm
• Trademark：TYM
• Origin：China
• HS Code：8474201000
• Production Capacity：60 Sets,Month

Model
Feeding opening size(mm)
Max.Feeding(mm)
Adjustment range of discharging opening(mm)
Capacity(t/h)
Power(kw)
Overall drmension(mm)
Pe-250×400
400×250
200
20-50
5-20
15
1430×1310×1340
Pe-400×600
600×400
350
40-100
15-60
30-37
1700×1732×1653
Pe-500×750
500×750
425
50-100
40-110
45-55
2035×1921×2000
Pe-600×900
900×600
480
65-160
90-180
55-75
2290×2206×2370
Pe-750×1060
1060×750
630
80-140
110-320
90-110
2655×2302×3110
Pe-900×1200
900×1200
750
95-165
220-450
110-132
3800×3166×3045
Pe-1000×1200
1000×1200
850
195-265
315-550
110-132
3800×3166×3045
Pe-1200×1500
1200×1500
1020
150-300
400-800
160-220
3800×3166×3045
Pex-150×250
150×250
125
10-40
1-3
5.5
896×745×935
Pex-150×750
150×750
125
18-48
5-16
15
1200×1500×1200
Pex-250×750
750×250
210
25-60
15-30
22-30
1667×1545×1020
Pex-250×1000
1000×250
210
25-60
15-50
30-37
1550×1964×1380
Pex-250×1200
1200×250
210
25-60
20-60
37-45
2192×1900×1950Pre-sale services:
(1) device model choice.
(2) According to customer's special requirements, design and manufacture of products.
(3) Training technical personnel for clients.
(4) The company is free of charge to the user on-site engineering and technical personnel planning site for the user to design the  best processes and program

Sales tracking :
(1) product acceptance.
(2) to help customers develop construction programs.

After-sale services :
(1) free to assign a dedicated service personnel, arriving at the scene and guiding  customers' installation.
(2) equipment installation.
(3) on-site training of operators.
(4) complete sets of equipment installed, 1-2 full-time technical staff to stay free of charge to help customers on-site production of 1 month, until the user' satisfactionRelated Products
