Stone Automatic Polishing Machine for Granite, Marble
Fujian Wanlong Diamond Tool Co., Ltd.- Type：Stone Polishing Machine
- Control：Artificial
- Automation：Automatic
- Precision：High Precision
- Application：Ceramics, Glass, Jadestone, Cement Brick, Concrete Curb, Granite, Marble
- Type for Grinding Machine：Disc Grinding Machine
Base Info
- Grinding Machine Type：Vibration Polishing Machine
- Grinding Method：Wet Grind
- Certification：API, ISO, CE
- Condition：New
- Polishing Head：20PCS
- Color：Yellow
- Voltage：380V, 50Hz
- Polishing Slab Thickness：15-50mm
- Transport Package：Fully Wrapped with Waterproof Membrane, 1 40FT Gp
- Specification：9200X2200X2200mm
- Trademark：Wanlong
- Origin：Quanzhou City, China
- HS Code：8464209000
- Production Capacity：100sets Per Month
Description
Technical Parameters
Model
LXM-10
LXM-12
LXM-16
LXM-20
Working wideth (Optional)(mm)
500-1300
500-1300
500-1300
500-1300
Thickness (mm)
15-50
15-50
15-50
15-50
Conveyor Speed (m/min)
0-2.6
0-2.6
0-2.6
0-3.0
Polishing Heads Number (pcs)
10
12
16
20
Water consumption (m3//h)
11
13
18
22
Air Consumption (m3/h)
12
14
19
24
Main Motor Power (KW)
8x7.5kw+2x9kw
9x7.5kw+3x9kw
12x7.5kw+4x9kw
16x7.5kw+4x9kw
Total Power (KW)
88.5
105
135
162
Dimension (LxWxH) (m)
5960x2200x2200
6600x2200x2200
7900x2200x2200
9200x2200x2200
