Shanghai High Capacity Sand Making Plant Supplier
ATAIRAC ENGINEERED PRODUCTS INC(CHINA)- Type：Impact Crusher
- Application：Chemical, Construction, Mineral Industry, Stone Industry
- Drive：Electric
- Crushing Style：Grinding & Impact
- Compressive Strength (For Crushing)：100-250MPA
- Crushing Degree：Fine Grinding Machine
Base Info
- Model NO.：VSI-1000II
- Finished Surface：Outer Surface Process
- Certification：CE, ISO
- Condition：New
- Max. Feeding Size (mm)：180
- Impeller Rotating Speed(R/Min)：430-640
- Capacity (T/H)：50-70
- Impact Plate Life：6 Months
- Transport Package：The Crusher Should Be Processed to Be Rustproo
- Specification：13.3T
- Trademark：ATAIRAC
- Origin：China
- Production Capacity：500 Units,Year
Description
Optional Configuration
(1) Feeding control device
Manual hydraulic pump is optional to adjust the flow into impeller, at the same time, by adjusting the vertical position of distributor plate, the proportion of impeller feeding flow and cascade flow into crushing chamber could be controlled accurately.
(2) Simple and easy-to-use lifting device
Hanging type manual or electric hoist is optional for the crusher. During crusher maintenance, this lifting device could easily and conveniently lift the upper cover, feeding hopper, distributor, impeller, main shaft, etc.
The device is optional designed for this crusher, which could jack up the feeding hopper and rotate it aside.
(4)Multifunctional crushing chamber
This crusher has two crushing mechanisms: "Stone-stone" and "Stone-steel", and two mechanisms are convertible in one crushing chamber by simple parts replacement, so as to satisfy requirement of different crushing environment and raw material.
(5)Oil lubrication and automatic control system
The oil lubrication system and PLC control and inspection system is optional for installation to monitor feeding quantity, current, oil temperature, main shaft temperature, the system can also realize vibrating protection function.
Service and Training
