Multi Blades High Efficiency Granite Stone Block Cutting Machine

Xiamen Great Base Imp & Exp Co., Ltd.

Type：electrical cutting machine
Usage：Granite, Marble
Application：Stone Industry
Source Voltage：380V
Automation：Automatic
Cutting Ability：High Speed

Base Info

Model NO.：GBTS-1200,1600
Control：Artificial
Certification：ISO, CE
function：cut thick slab
Operation：cutting stone
Use：cut curb stone
Transport Package：Nude Package
Specification：5500*2500*3500mm
Trademark：Great Base
Origin：China
HS Code：84641090
Production Capacity：200sets,Year

Description

NameUnitGBTS-1200GBTS-1600Main motorkw3745Cutter up/down strokemm500750Worktable sizemm2500*13002500*1300Saw blade sizemmmax.8pcs D.1200max.6pcs D.1600Outsizemm5500*2500*30005500*2500*3500Weightkg60007000 Multi Blades High Efficiency Granite Stone Block Cutting Machine

Multi Blades High Efficiency Granite Stone Block Cutting Machine

Category

Artificial Stone Machinery

Other Stone Processing Machinery

Stone Carving Machine

Stone Crusher

Stone Cutting Machine

Stone Drilling Machine

Stone Polishing & Grinding Machine

Recommended

Granite Marble Stone Mosaic Polishing Machine
50mm
Multi Blades Marble Mosaic Cutting Machine Mosaic Tile Making Machine
GBPGP-300No. of spindle head1pcBelt width320mmBlade diameter¢300-¢400 mmMain motor22kwMotor of belt1.5KWUp/down motor0.55KWMax. cutting width300mmMax. cutting thickness150MMTotal power24.05kwBelt speed1-3m/minuteDimension2500*1000*1700mmTotal weight1400kg
Mosaic Stone Calibration Machine Mosaic Making Machine
NameUnitGBPG-400DGBPG-600DGBPG-800DGBPG-1000DSpindle headpcs2222Belt widthmm4506508501050Calibration pad diametermm¢450¢650¢850¢1050Max. processing widthmm4006008001000Max. processing thicknessmm60606060Main motor powerkw1518.518.518.5Belt motor powerkw1.51.51.51.5Total powerkw32
Hydraulic Multi Discs Stone Cutting Machine Granite Cutting Machine
NameUnitGBQQJ-2000GBQQJ-2500CBlade diameter mmTotal 6pcs, Max.Ф2000Total 9pcs, Max.ф2500Max. cutting sizemm3500*2300*8003200*2300*1050Main motor power kw4555Girder length mm75007500Water consumption m3/h1212Weightkg900010000
Stone Dust Cleaning Machine for sale
NameUnitGBSQ-30GBSQ-40GBSQ-50Fan motorkw1.11.11.1Fan model/SFG-6-4SFG-6-4SFG-6-4Fan numberpcs345Air pressurekpa0.60.60.6Total air volumem³/h37500-4000050000-6000062500-75000Clean effect/Above 90%Above 90%Above 90%Suction of equipmentm/s1.8-2.21.8-2.21.8-2.2Noise valuedb80-8580-8580-85Dimension(
Pulsed Stone Dust Dry Cleaning Machine for sale
NameUnitGBML-S-30GBML-S-40GBML-S-50Fan motorkw2.22.22.2Fan model/GFK4.SDFK4.SDFK4.SFan numberpcs234Air pressurekpa0.60.60.6Total air volumem³/h16000-2400024000-3600032000-48000Clean effect/Above 99.7%Above 99.7%Above 99.7%Pulse control device/Sxc-8A1-4Sxc-8A1-4Sxc-8A1-4Suction of equipmentm/s2.
GBPGP-300 Automatic Continuous Cutting Machine
GBPGP-300No. of spindle head 1pcBelt width 320mm Blade diameter ¢300-¢400 mmMain motor 22kw Motor of belt 1.5KW Up/down motor 0.55KW Max. cutting width 300mm Max. cutting thickness 150MM Total power 24.05kw Belt speed 1-3m/minute Dimension 2500*1000*1700mmTotal weight 1400kg Main Features1
GBPGL-300 Mosaic Shaping Machine/Granite/Marble Machine
NameGBPGL-300No. of blade1pcMax. cutting width200mmMax. cutting length600mmMain motor11kwProcessing speed1-6m/minuteUp/down motor0.55kwDimension1550*1250*1700mmTotal power11.92kwTotal weight1100kgMain Features1) Machine with competitive price and high quality ,easy in installation and maintenance.2)
