• Model NO.：4030
• Motor Power：High Power
• Engraving Head Speed Adjustability：Wide Adjustable Range
• Certification：CE, ISO, API
• Current：AC
• Application：Glass, Ceramics, Decoration, Advertising, Art & Craft, Stela & Gravestone, Stone Industry
• Customized：Customized
• Service：Offering Oversea Service
• Voltage：220,110V
• Table：T-Slot Aluminum
• Spindle Power：2.2kw
• Driver：Leadshine or Servo
• Motor：Servo Motor,Stepper Motor
• X,Y,Z Traveling：400X300X120mm
• Metal Milling CNC：Aluminum Milling CNC Router
• Z Working Area：Metal Milling Cutter
• Carbon Steel CNC：Medal Engraving Machine
• Controller：Aluminum Medal Machine
• Medal Engraver：CNC Metal Engraving Machine
• Shoes Mould：CNC Shoes Mould
• Mould Machine：Shoes Mould
• Alumium Shoes Mould：Shoes Mould CNC
• Transport Package：Woodencase
• Specification：400x300x120MM
• Trademark：ALLWIN
• Origin：Jinan, Shandong
• HS Code：8465990000
• Production Capacity：50000

Model

ALLWIN-4030

Working Area

XYZ axis

400*300*120mm

Height

Z axis

120mm

Working Table

T slot aluminum alloy platform (straight ATC)

Move System

XYZ axis

XY: ball screw

Z: ball screw

servo motor

Control System

CNC system

WEIHONG / SYNTEC

Memory

512M

LCD Panel

5"LCD

Interface

USB

Accuracy

Moving

±0.005/300mm

Repeat

±0.005mm

DPI

0.002mm

Speed

Max.Moving Speed

30000mm/min

Max.Engraving Speed

20000mm/min

Software

Computer OS

Window98/2000/XP

Command

G-Code/HPGL-3D

Spindle

Power

2.2kw

Rotary speed

0-24000rpm

Collet

ER25-Φ3.175-Φ16

Power supply

AV

220V/50HZ

Lubrication System

Thin oil lubrication

Auto /Hand

Package

Weight

300kg

Dimension

700*600*1300mm

Working environment

Temperature

+5ºC to +35ºC

RH

30%-75%

Air pressure

86-106Kpa

PACKAGE AND SHIPPING:


FAQ:

1.How long about the machine's guarantee?
2 years
2.How about your after-sales service ?
Technical support by phone, WhatApp,Skype,e-mail or QQ around the clock.
3.How can we install the machine?
English version manual and operation video CD disk.
4.How about the payment terms?
30% T/T for deposit, 70%T/T paid before shipping. T/T, West Union, Paypal
5.Do you Arrange Shipment For The Machines?
Yes, dear customers, for FOB or CIF price, we will arrange shipment for you.
For EXW price, clients need to arrange shipment by themselves or their agents.
