Stone Processing Machinery

Professional Jaw Crusher, Jaw Crusher with Low Price (CGE-500)

Chemact (Liaoning) Petrochemicals Ltd.
  • Type:Jaw Crusher
  • Application:Chemical, Construction, Mineral Industry, Stone Industry
  • Drive:Electric
  • Crushing Style:Extruding & Milling
  • Compressive Strength (For Crushing):<300mpa
  • Crushing Degree:Coarse Crusher

Base Info

  • Model NO.:CGE-500
  • Power(W):70-220(Kw)
  • Capacity(T/H):50-900
  • Place of Origin:Shanghai, China (Mainland)
  • Brand Name:Chuangshen
  • Model Number:Cge Jaw Crusher
  • Dimension(L*W*H):According to The Stone Jaw Crusher
  • Warranty:Mainframe Is One Year (Excluding The Quick Wear PA
  • After-Sales Service Provided:Engineers Available to Service Machinery Overseas
  • Stationary/Mobile:Stationary, Mobile
  • Type of Crusher:Stone Jaw Crusher
  • Transport Package:Standard Packaging
  • Trademark:chuangshen

Description

Model Feed Opening Size
(WxH)(mm)
Max Feeding Size
(mm)
Discharging Size
(mm)
Capacity
(t/h)
Power
(kw)
Over dimensions
(LxWxH)(mm)
Weight(kg)
(exclude electric)
CGE-100 550x910 450 70-130 54-150 75-90 2000x2150 x1900 11000
CGE-200 630x910 550 50-180 125-290 90-110 2770x2330 x2600 18100
CGE-300 760x1065 650 100-170 210-420 110-132 2800x2500 x2840 28000
CGE-350 860x1065 750 200-270 240-500 110-132 2900x2500 x2840 28600
CGE-400 910x1220 750 75-220 280-570 160 3265x2925 x3845 56000
CGE-500 1060x1220 900 100-300 300-650 160-200 3415x2925 x3845 56700
CGE-600 1070x1370 900 90-220 395-720 185-200 3230x2910 X2970 59100
CGE-800 1220x1520 1100 115-250 530-950 220 3700x2980 x3030
