High Speed Multi Head Marble Stone Floor Grinding and Polishing Machine

Shandong Datang Machinery Technology Co., Ltd.
  • After-sales Service：Spare Parts
  • Warranty：1 Year
  • Type：Stone Polishing Machine
  • Control：CNC
  • Automation：Automatic
  • Precision：High Precision

Base Info

  • Model NO.：DTMJ
  • Application：Ceramics, Granite, Marble
  • Type for Grinding Machine：Disc Grinding Machine
  • Grinding Machine Type：Vibration Polishing Machine
  • Grinding Method：Wet Grind
  • Certification：ISO, CE
  • Condition：New
  • Polishing Head Qty.：12-24PCS
  • Conveyor Speed：0-3.5m,Min
  • Beam Swing Speed：0-48m,MIM
  • Processing Thickness：10-50mm
  • Water Consumption：15-20m3,H
  • Max. Polishing Width：1000,1260mm
  • Main Motor Power：7.5,11kw
  • Total Power：202kw
  • Productivity：800-1000m2,12h
  • Dimension：11000*3100*2400mm
  • Transport Package：Nude
  • Specification：12,14,16,20,24
  • Trademark：Datang
  • Origin：China
  • HS Code：8464209000
  • Production Capacity：300sets,Year

Description

ModelDTMJ-12-1260DTMJ-16-1260DTMJ-20-1260DTMJ-24-1260Polishing Head Qty.12pcs16pcs20pcs24pcsConveyor Speed0-3.5m/min0-3.5m/min0-3.5m/min0-3.5m/minBeam Swing Speed0-48m/min0-48m/min0-48m/min0-48m/minProcessing Thickness10-50mm10-50mm10-50mm10-50mmWater Consumption15-20m3/h15-20m3/h15-20m3/h15-20m3/hMax. Polishing Width1260mm1260mm1260mm1260mmMain Motor Power7.5/11kW7.5/11kW7.5/11kW7.5/11kWTotal Power104kW134kW167kW202kWDimension6900*3100*2400mm8100*3100*2400mm9300*3100*2400mm11000*3100*2400mm
