• Model NO.：PFW 1315
• Finished Surface：Hole Process
• Certification：ISO
• Condition：New
• Color：Iron Grey
• Spare Parts Supply：for Whole Year
• Test&Installation：Engineer Assigned
• After-Sale Service：for Whole Using Year
• Export Markets：Global
• Transport Package：Container, Nude Packs, in Bulk
• Specification：ISO9001: 2000
• Trademark：Zenith
• Origin：Shanghai Zenith, China
• HS Code：8474209000
• Production Capacity：40-850tph

Basic Info.

Model NO. PFW 1315 Finished Surface Hole Process Certification ISO Condition New Color Iron Grey Spare Parts Supply for Whole Year Test&Installation Engineer Assigned After-Sale Service for Whole Using Year Export Markets Global Transport Package Container, Nude Packs, in Bulk Specification ISO9001: 2000 Trademark Zenith Origin Shanghai Zenith, China HS Code 8474209000 Production Capacity 40-850tph

Product Description

Impact crusher Description:
As an experienced manufacture, Zenith has devoted in mining crushing and screening industry for many years. Due to the working principle, materials produced by traditional jaw crusher and cone crushers all contend many flakiness shape products. Particularly, for highway construction and some other major projects which have strict requirements on the aggregates, these aggregates are unqualified. After years of effort, Shanghai Zenith finally developed the new generation of impact crusher. The crushing capacity of new impact crusher has been improved substantially. Its product are all in cubic shape. What is more important that the keyless connection and the hydraulic arm activation technologies have reduced customer's operating costs and also facilitated maintenance. Impact crusher is generally use for secondary crushing in the stone production line. For it can both combined with and replace jaw crusher, impact crusher can not only be used for primary crushing but also secondary crushing. Shanghai zenith is famous impact cursher manufacturer and impact crusher supplier.

Impact crusher application:

Impact crusher, often used for secondary crushing stage, is designed by Zenith after absorbing the advanced technology from home and abroad. Among them, PF series is the latest and most popular impact crusher which provides customers with low cost solution, outstanding performance, good cubical shape, lowest operation cost and wide materials application. Impact crushers are more suitable to process limestone and widely used in ore crushing, railway, highway, energy, cement, chemical, construction and other industries.

Impact crusher supplier Features

1. Big feed opening; High crushing chamber;
2. Easy-adjusted clearance between impact plate and blow bar;
3. Cubical shape of final product and the output size is adjustable;
4. Three-curtain cavity design, high efficiency;
5. No-board connection;
6. Chrome hammer and special impact plate;
7. Adoption of hydraulic arm technology, easy maintenance.

Model	Rotor Φ×L (mm)	Feed Opening (mm)	Max Feeding (mm)	Capacity (t/h)	Power (kw)	Motor Model	Machine Size (mm)
PF1010	Φ1000×1050	400×1080	350	50-80	4-75	Y280S-4/75	2455×2086×2800
PF1210	Φ1250×1050	400×1080	350	60-120	6-110	Y315L1-6/110	2590×2050×2810
PF1214	Φ1250×1400	400×1430	350	80-160	6-132	Y315L2-6/132	2590×2400×2810
PF1315	Φ1300×1500	860×1520	350	120-260	6-200	Y355M3-6/200	2930×2760×3050
