Stone Processing Machinery

Hot Sale Mobile Stone Crusher Track Price

Shanghai Zenith Mineral Co., Ltd.
  • Application:Construction, Mineral Industry, Stone Industry
  • Drive:Electric

Base Info

  • Model NO.:LD series
  • Crushing Style:Grinding & Impact
  • Compressive Strength (For Crushing):>300MPA
  • Crushing Degree:Coarse Crusher
  • Finished Surface:Hole Process
  • Certification:CE, ISO, GOST
  • Condition:New
  • Color:Iron Grey
  • Spare Parts Supply:for Whole Year
  • Test&Installation:Engineer Assigned
  • After-Sale Service:for Whole Using Life
  • Export Markets:Global
  • Transport Package:Standard Container
  • Specification:ISO9001: 2008, SGS
  • Trademark:Zenith
  • Origin:Shanghai, China
  • HS Code:8474209000
  • Production Capacity:50-800tph

Description

Basic Info.

Model NO. LD series Crushing Style Grinding & Impact Compressive Strength (For Crushing) >300MPA Crushing Degree Coarse Crusher Finished Surface Hole Process Certification CE, ISO, GOST Condition New Color Iron Grey Spare Parts Supply for Whole Year Test&Installation Engineer Assigned After-Sale Service for Whole Using Life Export Markets Global Transport Package Standard Container Specification ISO9001: 2008, SGS Trademark Zenith Origin Shanghai, China HS Code 8474209000 Production Capacity 50-800tph

Product Description

hot sale mobile stone crusher track price

LD series stone crusher track (crawled mobile jaw crushing station) are the best solution of demolition recycling which heavily emphasizemobility and efficiency. The compact design ensures LD series crushing plants have the best transportability andmore crushing capacity.
Hot Sale Mobile Stone Crusher Track Price

Features of  stone crusher track

1. Incorporated design.
2. Truck mounted.
3. Quick road transportation.
4. With support legs on truck, quick to set-up.


Working principle of stone crusher track

Materials are evenly transported into the crusher by feeder, then be crushed by impact crusher, to realize circle crushing through closed system constituted by circular vibrating screen. Finished material will be discharged and transported through conveyor for continuous crushing operations. The circular vibrating screen of impact mobile crusher can be removed according to the actual production needs, to achieve the initial crushing of materials. The wheel mobile primary impact crusher is convenient and flexible to be used together with other crushing equipment.
Hot Sale Mobile Stone Crusher Track Price

stone crusher track parameters:
ModelLD-PE600x900LD-PE750x1060LD-PEW860
FeederGZD-960x3800GZD-960x3800GZD-1100x3800
Jaw CrusherPE600x900PE750x1060PEW860
Main ConveyorB800x8.5 MB1000x9 MB1000x9 M
Height of Main Conveyor (mm)320035003600
Side Conveyor(Optional)B450x3 MB500x3.5 MB500x3.5 M
Height of Side Conveyor (mm)280031003100
Generator (KW)180250300
Transport Length (mm)118001350013500
Transport Width (mm)290032003200
Transport Height (mm)366041204150
Total Weight (t)406063
