• Control：Artificial
• Precision：High Precision
• Application：Construction, Mineral Industry, Stone Industry
• Certification：ISO, CE
• Brand：Prodrill
• Air Pressure：0.4-0.63MPa
• Air Consumption：45 L,S
• Impact Frequency：31 Hz
• Transport Package：Wood Box
• Specification：CE, SGS
• Trademark：PRODRILL
• Origin：China
• HS Code：84671900
• Production Capacity：10000 PCS ,Month

Weight23KGSOver length610mmCylinder Bore66.7mmPiston stroke68mmAir consumption2.7M3/minWorking pressure0.4-0.5MpaShank size22*108mm
Ps.: Others
1. Besides high quality soundless cracking agent, we also sell other drilling, blasting tools:
Construction & Mining & Rock Drill Tools:
A. Down the hole (DTH) Bits and Hammers (drill hole dia.: 76 ~ 381mm): similar to DHD, MISSION series;
B. Top Hammer (drill hole dia.: 33 ~ 152mm): Threaded Tools (Button Bits, Rod, Coupling, Shank Adaptor): (item: R25 / R28/ R32 / R38 and T38 / T45 / T51, ST58, etc.);
C. Overburden Casing Drilling System

2. Advantages:
Compared with the oversea brands, our advantages are bellowing:
a. Our products can match over 95% against the original products
b. Price are competitive against the famous brands and best quality against the small factory

3. About Us:
1.    Our factory has been specialized in manufacturing drilling tools and spare parts for over 10 years.
2.    We have advanced technology and equipment.
3.    Our technician has more than 13 year's professional working experience.
4.    Rock drilling tools are exported throughout the world. Main market: Norway, Turkey, USA, Canada, Australia, Brazil, Uruguay, Iran, Philippines, Thailand, India, etc.
 ModelY6Y8Y10Y20Y19AY24Y26Y28Weight(kg)66101819242626Air consumption (L/s)≤9.5<9.0≤92543≤50≤47 length (mm)426428458605600604650661shank (mm)15*8815*8815*8822*10822*10822*10822(25)*10822*108Bore Dia (mm)2020-3020-3030-4230-4230-4230-4234-42Drill depth (m)0.50.50.535555Impact rate (Hz)5151≥5134353027≥28Hose connection(mm)13  16 or19191919 Air pressure(Mpa)0.40.4-0.630.2-0.3  0.40.40.4
