• Model NO.：Discovery 5
• Cutting Ability：High Speed
• Control：CNC
• Certification：ISO, CE
• Worktable Rotating(Optional)：360°
• Max Processing Size：2600*2600X1500mm
• Dimension of Worktable：1400*2000mm
• Water Consumption：4m3,H
• Main Motor：11kw
• Weight：7500kg
• Condition：New
• Specification：8000*6500*4100mm
• Trademark：XIANDA
• Origin：Fujian, China
• HS Code：8464109000
• Production Capacity：1000 Sets Per Year

Basic Info.

Model NO. Discovery 5 Cutting Ability High Speed Control CNC Certification ISO, CE Worktable Rotating(Optional) 360° Max Processing Size 2600*2600X1500mm Dimension of Worktable 1400*2000mm Water Consumption 4m3/H Main Motor 11kw Weight 7500kg Condition New Specification 8000*6500*4100mm Trademark XIANDA Origin Fujian, China HS Code 8464109000 Production Capacity 1000 Sets Per Year

Product Description

Discvoery  5 adopts 5 axis CNC control system, it can process different size arc slabs, column , roman column,number, letter , chinese words also diffrere nt shapes of marble or granite.
and It can also process

1. It has heavy load bearing structure, four orbits on each upright column, adjusted the balance by the rollers, with less friction and higher precision.

2. The left and right frame achieve synchronized lifting by steering equipment on the upper frame. The lifting accuracy increased by the conbine of lead screw and double nuts.

3. Cantilever part, firstly the lead screw and pole adjust the distance of guide wheel,guide wheel is controlled by CNC. Secondly in order to make the diamond wire rope cutting direction coincidence, reducer control the guide wheel rotating angle.

4. Worktable is running by lead screw and railway.

5. There has automatic alarm and memory function if wire broken, on top of it.

6. Aluminum wheel diameter is 1600mm.One fly wheel slide through sheave, oil pump control rope tension.


ITEM NO.	Discovery 5
Max processing size	2600x2600x1500mm
Dimension of worktable	2000x1400mm
Main Motor	11kw
Water consuption	4m³/h
Outline dimension	8000X6300X3800mm
Gross weight	7000kgs





Factory Overviews

Certifications



Exhibition


Our Services



We can provide Machine Testing Video and will be strict inspected and testing for every machines before shipping out.

32 years' Manufacture Experience.Special shape stone cutting machine more than 70% market occupied in China.

Top 5 stone cutting machine manufacturer with ISO&CE certificate.

Products are selling to more than 20 countries, with more than 10 years overseas experience.Use of top brands to ensure high quality.

We can provide competitive price and discount for large quantity.Strength supply capacity ,more 1000 sets per year.

After-sales service 24 hour on line. We will service staff training, so that continuously improve the overall quality of service.

We are responsible for receiving and processing customers on product quality and service quality complaints; We have professional and technical personnel to guide the installation and commissioning of your machine and operator training.
