Pew Series Jaw Crusher Hydraulic Jaw Crusher (PEW760/PEW860)
Shanghai Zenith Mineral Co., Ltd.- Type：Jaw Crusher
- Application：Construction, Mineral Industry, Stone Industry
- Drive：Electric
- Crushing Style：Grinding & Impact
- Compressive Strength (For Crushing)：>300MPA
- Crushing Degree：Coarse Crusher
Base Info
- Model NO.：PEW760,PEW860
- Finished Surface：Hole Process
- Certification：CE, ISO
- Condition：New
- Color：Iron Grey
- Spare Parts Supply：for Whole Year
- Test&Installation：Engineer Assigned
- After-Sale Sevice：for Whole Using Life
- Export Markets：Global
- Transport Package：Container, Nude Packs, in Bulk
- Specification：ISO9001: 2000
- Trademark：Zenith
- Origin：China
- HS Code：8474209000
- Production Capacity：50-350tph
Description
Basic Info.
Model NO. PEW760/PEW860 Finished Surface Hole Process Certification CE, ISO Condition New Color Iron Grey Spare Parts Supply for Whole Year Test&Installation Engineer Assigned After-Sale Sevice for Whole Using Life Export Markets Global Transport Package Container, Nude Packs, in Bulk Specification ISO9001: 2000 Trademark Zenith Origin China HS Code 8474209000 Production Capacity 50-350tphProduct Description
PEW Series Jaw Crusher Introduction
New generation crusher, pew series jaw crusher is born with innovative significance. It is newly designed and improved by our experts on basis of their more than 20 years' crusher manufacturing and designing experience. The unique design concept makes this series crusher achieve perfect combination between crushing efficiency and operating cost. Meanwhile, it has wide range of application, particularly suitable for crushing hard rock, such as basalt, river pebbles.
The features of PEW series Jaw crusher:
1. Durable moving jaw assembly.
2. Integral cast steel bearing housings.
3. Fast and safe setting adjustment.
4. Reasonable cavity design.
5. Larger-size and larger-carrying-capacity bearings
6. Compact & robust structure
PEW Series Jaw Crusher parameters:
| Model | Feed Inlet Size (mm) | Max Feed Size (mm) | Outlet Range (mm) | Capacity (t/h) | Motor Power (KW) | Weight (ton) | Overall Dimension(mm) |
| PEW760 | 760x1100 | 620 | 75-200 | 150-350 | 110-132 | 24 | 2600× 2500× 2200 |
| PEW860 | 860x1100 | 720 | 100-225 | 200-500 | 132-160 | 32 | 3300× 2320× 3120 |
| PEW1100 | 1100x1200 | 930 | 150-275 | 300-650 | 185-200 | 59.2 | 4140× 2660× 3560 |
| PEW400x600 | 400x600 | 350 | 35-85 | 15-70 | 37 | 6.8 | 1920× 1460× 1840 |
| PEW250x1200 | 250x1200 | 220 | 20-40 | 20-50 | 37 | 6 | 1400× 2050× 1310 |
| PEW250x1000 | 250x1000 | 220 | 20-40 | 15-50 | 30 | 5.6 | 1400× 1850× 1310 |
