Internal Combustion Rock Drill Yn27c/Yn27t/Yn27j/Yn27A
Fuzhou Golden Moral Imp & Exp Co., Ltd.- Type：Core Drill
- Drill Direction：Horizontal
- Depth of Drilling：0-100 M
- Drilling Speed：Optional
- Automation：Semi-automatic
- Layout：Horizontal
Base Info
- Model NO.：YN27C,YN27T,YN27J,YN27A
- Control：Optional
- Precision：Normal Precision
- Application：Machinery & Hardware, Construction, Mineral Industry, Stone Industry
- Certification：ISO, CE
- Certificate：CE
- Transport Package：Wood and Cartons
- Specification：CE
- Trademark：GM
- Origin：China
- Production Capacity：5000unit,Year
Description
Basic Info.
Model NO. YN27C/YN27T/YN27J/YN27A Control Optional Precision Normal Precision Application Machinery & Hardware, Construction, Mineral Industry, Stone Industry Certification ISO, CE Certificate CE Transport Package Wood and Cartons Specification CE Trademark GM Origin China Production Capacity 5000unit/YearProduct Description
Internal Combustion rock drill YN27C/YN27T/YN27J/YN27A: Internal Combustion Rock Drill has functions of drilling hole, cleavage, bruising, tamping and chiseling. It is widely used in mine, road construction, quarrying, national defense works, etc.TECHNICAL SPECIFICATIONS Weight of main machine 27 kgType of carburetor Hand needle valve, no floating type Ignition system Controllable silicon , contactless system Displacement of engine piston 185 cm3Rotating speed of engine ≥2450 r/minRotating speed of drill rod ≥200 r/minEnd of drill rod dimensions Hexagonal 22x108 mmMax drilling depth 6 mTank capacity 1.14 LDrilling speed ≥250mm/minMixture ratio of gasoline and lubricating oil(in volumes) 12:1Clearance of spark plug 0.5~0.7 mm
