• Model NO.：PE500x750, PE600x900, PE750x1060, PE900x1200
• Finished Surface：Hole Process
• Certification：CE, ISO, GOST
• Condition：New
• Color：Iron Grey
• Spare Parts Supply：for Whole Year
• Test&Installation：Engineer Assigned
• After-Sale Service：for Whole Using Life
• Export Markets：Global
• Transport Package：Container, Nude Packs, in Bulk
• Specification：ISO9001: 2000
• Trademark：Zenith
• Origin：China
• HS Code：8474209000
• Production Capacity：4-85tph

Basic Info.

Model NO. PE500x750, PE600x900, PE750x1060, PE900x1200 Finished Surface Hole Process Certification CE, ISO, GOST Condition New Color Iron Grey Spare Parts Supply for Whole Year Test&Installation Engineer Assigned After-Sale Service for Whole Using Life Export Markets Global Transport Package Container, Nude Packs, in Bulk Specification ISO9001: 2000 Trademark Zenith Origin China HS Code 8474209000 Production Capacity 4-85tph

Product Description

Small Jaw Crusher , Mini Stone Crusher price

PE series mini stone crushers are single toggle jaw crushers.It is one of the most commonly used crushers in industrial production. They are  widely applied in coarse and medium reduction of various kinds of ores and rocks with compressive strength under 350 MPa.


Working principle of Small Jaw Crusher , Mini Stone Crusher price

PE series mini stone crusher have a crushing chamber which is composed of a movable jaw, a stationary jaw and a edge plate. Driven by electric motor, via motorpully, V-belt and sheave driving eccentric shaft that make movable jaw move in accordance with pre-selected track cause crushing the material which are in the crushing chamber and setting the crushed material by the discharge gate. PE series jaw crushers have advanced features such as high reduction ratio, product size uniform, long service time, simple construction, outstanding reliability, easy maintenance, low energy consumption etc. Therefore, PE series are the top priority products as the primary crushing. They are widely applied in mining, road&railway, concrete, chemical and building material industries.


Application of Small Jaw Crusher , Mini Stone Crusher price:

1.widely applied in mining, road&railway, concrete, chemical and building material industries.
2.Ores and rocks with various hardness
3.Concrete basis and steel structure basis
4.Stationary, half-mobile and mobile applications



Main Advantages of Small Jaw Crusher , Mini Stone Crusher price:

1. The machine has a deep crushing cavity and the frame employs the joggle joint welding and entirely annealing technology which make the crusher a simple, durable and robust structure and improve the capability and the crushing ratio.
2.Digital simulation of the operating trace and speed of the movable jaw ensure a high capacity and low consumption rate of the ware parts.
3.Utilization rate of the tooth plate has been increased by using segmented tooth plates which are replaceable.
4.Hydraulic adjustment of the discharge opening ensures a more convenient and safe operation.
5.The service life of the toggle plate and adjustment seat has been developed by the double-layer adjustment seat with arc-shape liner inside it which will disperse the partial pressure evenly.
6.The frame could be taken into upper part and lower part which can be fixed together again by dowel pins. This sort of structure makes users easy to assembly, disassembly, transport and install the crusher.
7.The PE series mimi stone crusher employ the American technology.


Technical data of Small Jaw Crusher , Mini Stone Crusher price


Model	Feed Opening (mm)	Max Feeding (mm)	Discharge Opening (mm)	Capacity (t/h)	REV (r/min)	Power (kw)	Motor Model	Machine Size (mm)
PE200×350	200×350	170	20-50	2-6	220	6-7.5	Y160M-6/7.5
PE250×400	250×400	210	20-60	5-20	310	6-15	Y180L-6/15	1450×1315×1296
PE250×750	250×750	210	20-60	8-22	320	6-30	Y225M-6/30
PE500×750	500×750	425	50-100	45-100	275	6-55	Y280M-6/55	1890×1916×1870
PE600×900	600×900	500	65-160	70-120	250	6-75	Y315S-6/75	2520×1840×2303
PE750×1060	750×1060	630	80-140	130-260	250	8-90	Y315L1-8/90	2620×2302×3110
PE900×1200	900×1200	750	95-165	220-380	200	8-130	JR127-8/130	3789×2826×3025
PE1000×1200	1000×1200	850	195-265	230-380	200	8-130	JR127-8/130	3889×2826×3025
PE1200×1500	1200×1500	1020	150-300	400-800	220	8-200	YR355M4-8/200	4930×3150×3700
