• Model NO.：1325
• Engraving Head Speed Adjustability：Wide Adjustable Range
• Certification：CE
• Current：AC
• Application：Glass, Stone Industry
• Customized：Customized
• Working Area：1300*2500*300mm
• Spindle：Water Cooling Spindle(Optional Air Cooling)
• Spindle Speed：600-24000rpm
• Table：Aluminum T-Slot Table
• Transmission：Helical Rack
• Motors：Stepper Motor
• Control System：Ncstudio Control System
• Inverter：Sunfar Inverter
• Delivery Time：15 Working Days
• Transport Package：Exporting Plywood Package
• Specification：CE
• Trademark：ZHONGKE
• Origin：China
• HS Code：8465990000
• Production Capacity：100 Sets,Month

Spec.

ZK-1325 model

Processing size

1300mm*2500mm*300mm

Spindle power

2.2/3.2/5.5KW(Customizable)

Driving system

Step/Hybrid Servo/Servo(Customizable)

Motor drive

Handle,Stepper

Cooling system

Water-cooling spindle

Machine precision

0.05mm

Working voltage

AC 220v/50Hz or 380v/50Hz

Lathe bed

Heavy-duty square pipe welding bed, stainless steel sink , stainless steel plate

Rack

 Precision helical drive

Guide

Taiwan , Shangyin

Screw

Taiwan

Spindle speed

6000-24000

The case

Machine box bed body structure

The inverter

2.2/3.7/5.5KW(Customizable)

mesa

The aluminum profile is attached with PVC board and customized t-shaped rod for stone carving

Lubrication system

Automatic oil filling system

instruction

G-code,*u00,*mmg,*plt

Application:

Mainly applied to tombstone processing industry, home decoration industry ,arts and crafts etc industries ,mainly process on granite ,marble , glass ,ceramic, white marble ,jade, blue stone ,sandstone ,black brick , Plastic, foam etc materials.
