• Model NO.：CSCB
• Certification：CE, ISO, GOST, SONCAP, UL, CCC, API
• Condition：New
• Color：Iron Grey
• Certificate：ISO 9001:2008
• Crusher Materials：Rock, Quarry, Ore, Stone, Mining, Coal and So on
• Colour：as Customer Request
• Quality：China Standard
• Capacity(T/H)：200-600
• Max Feeding Size(Mm)：50
• Vertical Shaft Impact Crusher Price：Too Low
• Type of Crusher：Vertical Shaft Impact Crusher
• Sand Making Machine Are Suitable for：Any Demanding Crushing Application
• Transport Package：Standard Packaging
• Specification：Industrial grade
• Trademark：Chuangshen
• Origin：Shanghai China
• Production Capacity：50sets Per Month

Basic Info.

Model NO. CSCB Certification CE, ISO, GOST, SONCAP, UL, CCC, API Condition New Color Iron Grey Certificate ISO 9001:2008 Crusher Materials Rock, Quarry, Ore, Stone, Mining, Coal and So on Colour as Customer Request Quality China Standard Capacity(T/H) 200-600 Max Feeding Size(Mm) 50 Vertical Shaft Impact Crusher Price Too Low Type of Crusher Vertical Shaft Impact Crusher Sand Making Machine Are Suitable for Any Demanding Crushing Application Transport Package Standard Packaging Specification Industrial grade Trademark Chuangshen Origin Shanghai China Production Capacity 50sets Per Month

Product Description

1000 type rock crushers,1000 type rock sand crusher



I.Vertical Shaft Impact Crusher, sand making machine for sale

Vertical shaft impact crushers also called sand making machines, are fine crusher styles based on the principle of impact and attrition. Vertical shaft impact crushers are appropriate for various environments, especially for crushing brittle, hardness and grind materials. Vertical shaft impact crushers

II.Vertical Shaft Impact Crusher, sand making machine appropriate for

Brittle hardness and grind materials such as ore, concrete, limestone, cobble, granite, metallurgy slag Secondary, tertiary and fine crushing stages or coarse grinding stage or shaped aggregate stage. Artificial sand making, concrete, beneficiation and grinding used in modern construction, irrigation works, building and mining industrials.

III.Main advantages of vertical shaft impact crushers, sand making machine



(1)CSCB (F) (L)/CPL(S) series are based on the U.S. technology and it is currently the world's most advanced sand making equipment.



(2)Shell of product rotor with high wear-resistant liner and alloy of tungsten carbide blade assembly form, eliminating the need and cost to purchase new welding rotor or rotor`s shell.



(3)Oil lubrication system comprised of filter, oil cooler, oil heater, temperature switch. Increasing the speed of the rotor, reducing the possibility of misoperation.



(4)360 ° rotating hydraulic device for open the top cover (operational choice) will be easy for replacement of wearing parts and convenient to maintenance time of equipment and labor intensity.

IV.Vertical Shaft Impact Crusher, sand making machine Specification

Model	Max Feed Size(mm)	Eccentric Shaft Speed(r/min)	Capacity(t/h)	Power(kw)	Weight(kg)
CSCB-850	50	800-1800	200-350	(110-200)x2	10950
CSCBF-850	50	800-1800	200-350	(110-200)x2	13350
CSCBL-850	50	800-1800	250-400	(110-200)x2	10980
CSCB-1000	63	800-1800	350-600	(200-250)x2	13730
CSCBF-1000	63	800-1800	350-600	(200-250)x2	16380
CSCBL-1000	63	800-1800	450-600	(200-250)x2	13990
CPL(ST)-550	30	2258-2600	40-60	30-45	4730(5300)
CPL(ST)-700	35	1775-2050	80-100	55-90	7150(7750)
CPL(ST)-850	50	1460-1720	100-240	150-220	11680(12350)
CPL(ST)-1000	60	1240-1460	150-320	220-320	15800(17300)
CPL(ST)-1200	60	950-1220	200-500	320-500	20150(22500)
